Rebates & Special Offers
View Full OfferGet as low as 0% for 60 months* or Up to $43,500 cash back* in lieu of financing.
- Horsepower
- 337.9 hp
- Max dig depth
- 25' 0"
- Operating weight
- 97,718 lb
- Bucket digging force
- 55,078 lbf
More specifications
|
General Info
|
|
|---|---|
| Condition: | Showroom |
| Manufacturer: | Develon |
| Model: | DX420LC-7 |
| Machine Type: | Other |
|
Engine
|
|
|---|---|
| Engine: | DC13 |
| Engine Make: | Scania |
| Horsepower: | 337.9 |
| Emissions: | Tier 4 |
|
Performance
|
|
|---|---|
| Bucket Digging Force: | 55,078 lbf. |
| Arm Digging Force: | 41,365 lbf. |
| Max Digging Reach (Ground): | 36' 9" |
| Max Digging Depth: | 25' 0" |
| Operating Weight: | 97718 lb |
|
Hydraulics
|
|---|
|
Dimensions
|
|
|---|---|
| Fuel Tank: | 166.43 gal. |
Description
Develon DX420LC-7
Dig With Confidence
A leader in the 40- to 50-metric-ton size class, the DEVELON DX420LC-7 crawler excavator provides impressive digging forces and is available in standard arm or long arm configurations.
Superior hydraulics fuel powerful digging forces, and a one-touch power boost momentarily amplifies hydraulic power to help you take on difficult digging conditions that slow other machines down. It delivers high breakout forces with ultra-hard wear plates that bolt on the end of the machine arm for maximum durability. It all adds up to exceptional productivity.
Fast cycle times, strong swing torque and improved lifting capacity help you do more in a day’s work.
Choose from four selectable power modes and use the fine swing function for more control in certain lifting applications.
The optional intelligent floating boom mode allows the boom to move freely with the contours of the ground and when engaged doesn’t use hydraulic flow, increasing efficiency and productivity.
Do More in Comfort
The DX420LC-7 excavator offers comfort features and easy-to-use controls to help operators stay focused.
Ergonomically designed joystick and fingertip controls are intuitive and easy to use, and the multi-function DEVELON Smart Touch display is standard, offering all important settings on one screen.
Front, side, rear and overhead windows and a standard rearview camera improve visibility. An optional 360-degree all-around view monitoring (AVM) camera system is also available, providing a full view of the machine’s surroundings. Other updates include an advanced heating and cooling system and optional heated/cooled seat.
Fuel Efficiency Is Standard
To help keep fuel expenses low, the DX420LC-7 offers standard systems that help improve fuel efficiency while maintaining the productivity your work demands.
Several advanced technologies, including D-ECOPOWER™ system , Smart Power Control (SPC) and the Electronic Power Optimizing System (EPOS), help optimize machine productivity while reducing fuel consumption.
The Tier 4-compliant DEVELON diesel engine delivers more power output and reduces fuel consumption, and the auto shutdown and auto idle features also help lower fuel usage.
Loan
Lease
Cash in Lieu
Warranty
See participating dealers for details.
*Program disclosure: 0% A.P.R. financing for up to 60 months and the cash-in-lieu rebate are mutually exclusive — select one or the other. Select models also carry an additional rebate that can be combined with either financing or cash in lieu; the up to $43,500 amount shown includes it. Lease options are available separately; contact dealer for terms and custom payment structures. Financing subject to credit approval through an authorized Develon financing provider. Rebate applied at time of purchase. 3 Year / 3,000-Hour Full Coverage standard warranty included with qualifying new Develon equipment purchases. Offers valid on qualifying new Develon models through participating dealers only. See dealer for complete details, eligibility requirements, and program end dates. Offers subject to change without notice.
What Makes the DX420LC-7 Different
344.6 hp Scania Engine
The 12.7 L Scania DC13 delivers 344.6 net hp at 1,800 rpm for demanding digging, lifting and loading.
25 ft Standard-Arm Dig Depth
The standard configuration digs 25 ft deep, while the available long arm extends maximum depth to 27 ft 3 in.
64,374.3 lbf Bucket Force
Powerful hydraulics and one-touch power boost deliver high breakout force in difficult material.
D-ECOPOWER Hydraulics
Electronically controlled pumps, a closed-center valve and nine sensors supply the hydraulic oil each task requires.
Fine Swing Control
Fine swing reduces movement at the end of a swing for greater control and accuracy in lifting applications.
Smart Touch and Camera Visibility
A multifunction display and rearview camera are standard, with optional 360-degree all-around view monitoring.
Easy Ground-Level Maintenance
Ground-level filters, centralized grease banks and access panels on multiple sides simplify daily service.
Compare the Crawler Excavator Lineup
See where the DX420LC-7 fits among nearby DEVELON crawler excavators. Values are published North American base-machine figures.
 |
 |
 |
 |
 |
|
 |
 |
|
| DX140LC-7K | DX170LC-7 | DX180LC-5 | DX235LCR-7 | DX350LCR-7 | DX420LC-7 Viewing | DX490LC-7 | DX530LC-7 | |
|---|---|---|---|---|---|---|---|---|
| Rated Power (net) | 107.3 hp @ 2,000 rpm | 115.0 hp @ 2,000 rpm | 127.3 hp @ 2,000 rpm | 170.3 hp @ 1,900 rpm | 266.9 hp @ 1,800 rpm | 344.6 hp @ 1,800 rpm | 379.5 hp @ 1,800 rpm | 379.5 hp @ 1,800 rpm |
| Operating Weight | 31,746 lb | 38,360 lb | 41,667 lb | 57,132 lb | 79,701 lb | 94,527 lb | 121,676 lb | 121,804 lb |
| Maximum Dig Depth | 20 ft 1 in | 20 ft 2.9 in | 20 ft 0 in | 21 ft 11 in | 22 ft 10 in | 27 ft 3 in (long arm) | 27 ft 7 in (long arm) | 24 ft 0 in |
| Model Generation | -7K | -7 | -5 | -7 LCR | -7 LCR | -7 | -7 | -7 SLR available |
Specifications vary by configuration and are subject to change. Contact Carleton Equipment to confirm the machine for your application.
DX420LC-7 Features & Benefits
Performance & Efficiency 6
Scania DC13 Engine
The Tier 4-compliant 12.7 L six-cylinder produces 344.6 net hp and 1,178.9 lb-ft of gross torque.
Four Power Modes
Power+, Power, Standard and Economy modes balance performance and fuel consumption for changing workloads.
D-ECOPOWER System
Electronically controlled hydraulics deliver the oil flow each task demands for smooth response and improved efficiency.
Smart Power Control
SPC coordinates engine speed and pump torque to reduce unnecessary load while maintaining productivity.
Electronic Power Optimizing System
EPOS monitors and optimizes engine and hydraulic performance to improve control and reduce fuel use.
Auto Idle and Shutdown
Automatic idle and time-adjustable shutdown help reduce fuel consumption during inactive periods.
Digging, Lifting & Hydraulics 6
Standard and Long Arms
The standard arm digs 25 ft deep; the long-arm US30 configuration extends maximum depth to 27 ft 3 in.
Dual 95.1 gpm Main Pumps
Two high-capacity main pumps support strong combined functions, fast cycles and demanding attachments.
One-Touch Power Boost
Power boost delivers 64,374.3 lbf of bucket force and 46,737.5 lbf of arm force with the standard arm.
118,332.0 lbf-ft Swing Torque
Strong swing torque supports productive uphill swinging, truck loading and backfilling.
Fine Swing Function
Fine swing minimizes shaking of a suspended load at the end of swing movement.
Optional Intelligent Floating Boom
The boom can follow ground contours without hydraulic flow for efficient finishing and truck loading.
Comfort, Visibility & Technology 6
Smart Touch Display
The standard multilingual display consolidates operating information, machine settings and camera views.
Ergonomic Controls
Intuitive joystick and fingertip controls provide low-effort command of machine and attachment functions.
Advanced Climate Control
Automotive-style heating and cooling help operators remain productive in changing weather.
Optional Heated and Cooled Seat
An available deluxe air-suspension seat adds heating and cooling for year-round comfort.
Enhanced Visibility
Front, side, rear and overhead windows complement the standard rearview camera and optional 360-degree AVM.
MY DEVELON Fleet Management
Standard telematics provides remote access to location, health, productivity and maintenance information.
Durability & Serviceability 5
Heavy-Duty Front Design
Additional reinforcement at key stress points supports demanding excavation and lifting applications.
Bolt-On Wear Plates
Ultra-hard wear plates protect the end of the arm and simplify replacement in high-contact areas.
Ground-Level Filter Access
Routine filters and inspection points are positioned for convenient daily maintenance.
Centralized Grease Banks
Grease points on the arm and boom base are grouped to make regular lubrication faster.
Multiple Access Panels
Panels open from the top, bottom and sides to improve access to major components.
Why Buyers Choose the DX420LC-7
344.6 net hp for demanding 40- to 50-metric-ton-class production
25 ft standard-arm dig depth with a 27 ft 3 in long-arm option
64,374.3 lbf standard-arm bucket force with power boost
Dual 95.1 gpm pumps and 118,332.0 lbf-ft maximum swing torque
D-ECOPOWER, SPC and EPOS efficiency technologies
Four power modes, fine swing and optional intelligent floating boom
Standard rearview camera with optional 360-degree AVM
Ground-level filters, centralized grease banks and standard telematics
Who Uses the DX420LC-7 and What For
The DX420LC-7 gives heavy civil, site-development and material-handling contractors the digging force, lift capacity and hydraulic performance needed for high-production work.
Heavy Civil
- Road and bridge construction
- Large infrastructure excavation
- Deep utility installation
- Heavy structure placement
Site Development
- Mass excavation
- Foundation and basement work
- Truck loading
- Large commercial sites
Quarry & Aggregate
- Production digging
- Rock and overburden removal
- Crusher feeding
- Heavy bucket applications
Material Handling
- Heavy lifting and placement
- Grapple and thumb work
- Transfer-station loading
- High-flow attachment operation
The DX420LC-7 by the Numbers
Scania DC13 output at 1,800 rpm.
The headline standard-arm US15 configuration.
The long-arm configuration extends to 27 ft 3 in.
Standard-arm digging force with power boost.
D-ECOPOWER hydraulics supply task-matched flow.
Strong uphill swing and backfilling performance.
Talk to a person about the DX420LC-7
Carleton Equipment is a family-owned Michigan dealer, here since 1938. Sales, rental, service and parts all come from the same team, and we’ll connect you with the location nearest you.
- Chesterfield
- Coldwater
- Grand Rapids
- Howell
- Kalamazoo
- Livonia
- Saginaw
Full Specifications
Download Spec SheetGeneral
| Machine Type | Crawler excavator |
| Operating Weight | 94,527 lbs (US15) |
| Operating Weight, Standard Arm | 103,396 lbs (US20) |
| Operating Weight, Long Arm | 103,837 lbs (US30) |
| Ground Pressure | 8.2 psi (US15) / 8.1 psi (US20 and US30) |
| Bucket Capacity | 2.51 yd³ standard / 2.15 yd³ long arm |
| Counterweight | 17,920 lbs standard / 21,605 lbs long arm |
Engine
| Engine | Scania DC13 |
| Displacement | 12.7 L |
| Cylinders | 6 |
| Net Power | 344.6 hp @ 1,800 rpm |
| Gross Power | 344.6 hp @ 1,800 rpm |
| Maximum Torque | 1,178.9 lb-ft @ 800–1,500 rpm |
| Alternator | 28 V, 100 A |
| Battery | 2 × 12 V, 200 Ah |
Performance
| Maximum Dig Depth | 25 ft 0 in standard / 27 ft 3 in long arm |
| Maximum Reach | 37 ft 6 in standard / 39 ft 9.2 in long arm |
| Maximum Reach at Ground | 36 ft 9.3 in standard / 39 ft 0.9 in long arm |
| Maximum Loading Height | 25 ft 7.5 in standard / 26 ft 10.8 in long arm |
| Maximum Digging Height | 34 ft 9.9 in standard / 36 ft 2.8 in long arm |
| Bucket Digging Force | 64,374.3 lbf standard / 65,035.7 lbf long arm |
| Arm Digging Force | 46,737.5 lbf standard / 39,903.3 lbf long arm |
| Maximum Swing Torque | 118,332.0 lbf·ft |
| Swing Speed | 0–9.6 rpm |
| Travel Speed | 2.1–3.4 mph |
| Maximum Traction Force | 95,767.8 lbf |
| Gradeability | 35° / 70% |
Hydraulics
| Main Pumps | 2 electronically controlled pumps |
| Main Pump Flow | 2 × 95.1 gpm |
| Pilot Pump Flow | 6.3 gpm |
| Normal Implement Pressure | 4,980 psi |
| Power-Boost Pressure | 4,980 psi |
| Travel Pressure | 4,694 psi |
| Swing Pressure | 3,980 psi |
| Pilot Pressure | 586 psi |
Capacities
| Fuel Tank | 161.4 gal |
| DEF Tank | 16.6 gal |
| Cooling System | 13.9 gal |
| Engine Oil With Filter | 11.9 gal |
| Swing Drive | 2.1 gal |
| Final Drive, Each Side | 1.8 gal |
| Hydraulic System | 145.3 gal |
| Hydraulic Tank | 70.0 gal |
Dimensions
| Boom Length | 22 ft |
| Arm Length | 10 ft 8 in standard / 12 ft 11.5 in long arm |
| Tail Swing Radius | 12 ft 4 in |
| Shipping Length | 38 ft 6.2 in |
| Shipping Width | 11 ft 8 in (US15) / 11 ft 11.7 in (US20 and US30) |
| Cabin Height | 10 ft 6.4 in |
| Overall Track Length | 17 ft 1 in |
| Track Shoe Width | 31.5 in (US15) / 35.4 in (US20 and US30) |
| Car Body Clearance | 1 ft 11 in |
Operator & Technology
| Cab Sound Level | 71 dB(A) |
| Exterior Sound Level | 104 dB(A) |
| Display | DEVELON Smart Touch |
| Rearview Camera | Standard |
| 360-Degree AVM | Optional |
| Heated and Cooled Seat | Optional |
| Intelligent Floating Boom | Optional |
| MY DEVELON | Standard |
Values are from the current DEVELON North America DX420LC-7 product page, model-specification API and official sales specifications. US15 is the headline standard-arm configuration; US20 and long-arm US30 differences are labeled separately. Current web values take precedence over more precise PDF conversions where they differ. Specifications vary by arm, track, bucket and attachment configuration. Contact Carleton Equipment to confirm details.
