Bobcat® T770

Bobcat



2018 Bobcat® T770

With 11 ft. of vertical lift, the Bobcat® T770 compact track loader is primed for loading trucks, grinders and hoppers as well as many other jobs. The vertical lift path allows you to easily place cargo and tackle demanding tasks. The T770 is a Tier 4 model.

 Configuration

Engine



 Emissions Tier (EPA) Tier 4
Engine Cooling Liquid
Engine Fuel Diesel
Horsepower 92 hp
Turbocharged Engine

Optional

Performance

 Rated Operating Capacity (ISO) 3,475 lb
Operating Capacity (50% of Tip) 4,960 lb
Tipping Load 9,929 lb
Operating Weight 10,515 lb
Travel Speed 6 mph
Travel Speed (2 - Speed Option) 9.3 mph
Ground Pressure (Rubber) 4.2 psi

Capacities

 Fuel Tank 44.4 gal

Hydraulic System

System Relief @ Quick Couplers 3,500 psi
Auxiliary Std Flow 23 gal/min
Auxiliary High Flow 36.6 gal.min

Dimension

 Length 141.6 in
Length Without Attachment 114.3 in
Length With Standard Bucket 141.6 in
Width 78 in
Width (With Bucket)  80 in
Height 81.3 in
Height With Operator Cab 81.3 in
Height to Bucket Hinge Pin 132 in
Reach @ Maximum Height 33.6 in
Turning Radius 88 in
Length of Track on Ground

63.7 in

Track Width

17.7 in

Features may include:
  • Powerful Hydraulics
  • Durable Undercarriage
  • Standard & Advanced Control Systems
  • Selectable Joystick Control
  • Automatic Ride Control
  • 2-Speed Travel
  • Remote Control
  • Superior Lift Arms
  • Deluxe Instrumentation
  • Smart Cooling
  • Protected Components
  • Protection Technology
  • Simple Machine Tie-Downs
  • Cold Weather Protection
  • Premium Cab
  • Sound Dampening
  • Clear Visibility
  • Operator-Friendly Controls
  • Adjustable Seat
  • Maximum Headroom and Legroom
  • Pressurized Cab
  • Lift Cylinder Cushioning
  • Panoramic Serviceability
  • Grease Point Access
  • Hydraulic Oil Site Gauge
  • Transverse Engine and Belt Drive
  • Attachment Versatility
  • Power Bob-Tach System
  • Bob-Tach System
  • Deluxe Instrumentation
