Rebates & Special Offers
View Full OfferGet as low as 0% for 60 months* or Up to $43,500 cash back* in lieu of financing.
- Horsepower
- 115 hp
- Operating weight
- 38,360 lb
- Max dig depth
- 20 ft 2.9 in
- Ground-level reach
- 29 ft 1.5 in
More specifications
|
General Info
|
|
|---|---|
| Condition: | Showroom |
| Manufacturer: | Develon |
| Model: | DX170LC-7 |
| Machine Type: | Other |
|
Engine
|
|
|---|---|
| Engine: | D34 |
| Horsepower: | 115.0 |
|
Performance
|
|
|---|---|
| Operating Weight: | 38360 lb |
|
Hydraulics
|
|---|
|
Dimensions
|
|
|---|---|
| Fuel Tank: | 76 gal |
Description
Develon DX170LC-7
Easier Transportation for Greater Flexibility
The Develon DX170LC-7 is designed to simplify equipment transportation without sacrificing performance. Its narrow width and reduced operating weight make it an excellent choice for residential construction, landscaping, utility work, and light excavation. In many applications, the combined weight of the excavator, trailer, and Class 7 tow vehicle can remain under the 80,000-pound GVWR threshold, eliminating the need for special transport permits and making it easier to move between jobsites.
Powerful Performance with Precise Control
The DX170LC-7 delivers the power and versatility needed for a wide range of excavation tasks. Four selectable work modes allow operators to match machine performance to the application, while Smart Power Control (SPC) optimizes hydraulic and engine output to improve fuel efficiency without sacrificing productivity. Working alongside the Mechatronics system, the engine's electronic controls synchronize hydraulic performance, power delivery, fuel consumption, auto-idle, and machine diagnostics to provide smooth operation, precise grading, and responsive control in demanding conditions.
Operator Comfort and Convenience
Designed with operator productivity in mind, the DX170LC-7 features a modern cab that combines exceptional comfort with intuitive controls. A standard heated air-suspension seat with multiple adjustment options helps reduce fatigue, while an available heated and cooled seat provides additional comfort during extreme temperatures. Excellent visibility, high-performance climate control, ample storage, and ergonomic controls create a productive work environment. Operators using optional two-way auxiliary hydraulics can conveniently control attachments with either joystick-mounted buttons or an available foot pedal.
Advanced Display and Visibility
A standard 8-inch color LCD monitor provides easy access to machine settings, operating history, hydraulic flow adjustments, and maintenance information. Integrated split-screen capability allows operators to monitor machine data while simultaneously viewing live camera feeds. Standard rearview and side-view cameras improve visibility around the excavator, helping reduce blind spots and increase jobsite safety.
Built for Long-Term Durability
The DX170LC-7 is engineered for dependable performance in demanding environments. Its rugged D-type frame and reinforced chassis provide exceptional structural strength while minimizing frame distortion. A strengthened boom and arm assembly increase durability for heavy-duty applications, while polymer bucket pivot shims reduce wear and improve grease retention to help extend component life and reduce maintenance requirements.
Simplified Maintenance and Maximum Uptime
Routine maintenance is designed to be fast and convenient with centralized grease points and easy access to major service components, including the air cleaner, fuel filter, oil filter, radiators, and engine compartment. Extended service intervals, reinforced structural components, and durable construction help reduce downtime and ownership costs. Standard MY DEVELON fleet management allows owners to remotely monitor machine health, maintenance schedules, and operating performance to maximize uptime and improve fleet efficiency.
Efficient Tier 4 Performance
The DX170LC-7 meets Tier 4 emissions standards through an advanced high-pressure common-rail (HPCR) fuel system paired with cooled exhaust gas recirculation (CEGR), a diesel oxidation catalyst (DOC), and selective catalytic reduction (SCR). This efficient emissions technology delivers reliable power, reduced fuel consumption, and environmentally compliant performance for today's demanding jobsites.
Loan
Lease
Cash in Lieu
Warranty
See participating dealers for details.
*Program disclosure: 0% A.P.R. financing for up to 60 months and the cash-in-lieu rebate are mutually exclusive — select one or the other. Select models also carry an additional rebate that can be combined with either financing or cash in lieu; the up to $43,500 amount shown includes it. Lease options are available separately; contact dealer for terms and custom payment structures. Financing subject to credit approval through an authorized Develon financing provider. Rebate applied at time of purchase. 3 Year / 3,000-Hour Full Coverage standard warranty included with qualifying new Develon equipment purchases. Offers valid on qualifying new Develon models through participating dealers only. See dealer for complete details, eligibility requirements, and program end dates. Offers subject to change without notice.
What Makes the DX170LC-7 Different
Transport-Friendly 17-Ton Design
A narrow 8 ft 6 in width and reduced 38,360 lb operating weight help the machine, trailer and suitable tow vehicle stay below the 80,000 lb GVWR threshold.
115 hp DEVELON Engine
The 3.4 L DEVELON D34 delivers 115 net hp at 2,000 rpm and works with four power modes to match output to the application.
20 ft 2.9 in Dig Depth
The standard 8 ft 2.4 in arm provides productive digging reach for landscaping, residential basements, utilities and site development.
Smart Power Control
SPC varies engine speed and pump torque to improve efficiency while maintaining productive hydraulic performance.
Four Work Modes
Digging, lifting, breaker and shear modes help operators tune hydraulic response for the job and attachment.
Side and Rearview Cameras
Standard side and rear cameras display blind-spot views on the 8-inch monitor, including a split-screen view with critical machine information.
Heated Air-Suspension Seat
A heated air-suspension seat is standard, with seat cooling available for added comfort in demanding conditions.
Compare the Crawler Excavator Lineup
See where the DX170LC-7 fits among nearby DEVELON crawler excavators. Values are published North American base-machine figures.
 |
 |
|
 |
 |
 |
 |
 |
|
| DX140LC-7K | DX170LC-7 Viewing | DX180LC-5 | DX235LCR-7 | DX350LCR-7 | DX420LC-7 | DX490LC-7 | DX530LC-7 | |
|---|---|---|---|---|---|---|---|---|
| Rated Power (net) | 107.3 hp @ 2,000 rpm | 115.0 hp @ 2,000 rpm | 127.3 hp @ 2,000 rpm | 170.3 hp @ 1,900 rpm | 266.9 hp @ 1,800 rpm | 344.6 hp @ 1,800 rpm | 379.5 hp @ 1,800 rpm | 379.5 hp @ 1,800 rpm |
| Operating Weight | 31,746 lb | 38,360 lb | 41,667 lb | 57,132 lb | 79,701 lb | 94,527 lb | 121,676 lb | 121,804 lb |
| Maximum Dig Depth | 20 ft 1 in | 20 ft 2.9 in | 20 ft 0 in | 21 ft 11 in | 22 ft 10 in | 27 ft 3 in (long arm) | 27 ft 7 in (long arm) | 24 ft 0 in |
| Model Generation | -7K | -7 | -5 | -7 LCR | -7 LCR | -7 | -7 | -7 SLR available |
Specifications vary by configuration and are subject to change. Contact Carleton Equipment to confirm the machine for your application.
DX170LC-7 Features & Benefits
Performance & Control 6
DEVELON D34 Engine
The 3.4 L four-cylinder produces 115 net hp and 391 lb-ft of gross torque, pairing responsive performance with Tier 4 emissions technology.
Smart Power Control
Variable speed and pump torque control help improve machine efficiency while preserving productivity in digging mode.
Four Power Modes
P+, Power, Standard and Economy modes let the operator balance workgroup speed, performance and fuel consumption.
Four Work Modes
Digging, lifting, breaker and shear modes configure hydraulic response for common applications and attachments.
Mechatronics Design
Electronic synchronization of the engine and hydraulic system supports precise material placement, leveling and efficient fuel control.
Auto Idle & Auto Shutdown
Automatic idle and shutdown reduce unnecessary fuel consumption and accumulated engine hours when the machine is not working.
Digging, Hydraulics & Transport 6
20 ft 2.9 in Dig Depth
The standard arm reaches 20 ft 2.9 in deep and 29 ft 1.5 in at ground level for excavation and utility applications.
Dual 40.2 gpm Main Pumps
Tandem variable-displacement axial-piston pumps support smooth combined functions and responsive hydraulic attachments.
Power-Boost Digging Force
Power boost delivers 27,778 lbf of bucket force and 18,519 lbf of arm force for demanding excavation.
Optional Two-Way Auxiliary Hydraulics
When equipped with the optional two-way auxiliary hydraulics, operators can control attachments using the optional foot pedal or joystick buttons.
Transport-Friendly Width
The 8 ft 6 in shipping width and reduced machine weight simplify transport between landscaping, residential and light-excavation jobs.
Precise Material Placement
Coordinated electronic engine and hydraulic control helps operators place material accurately and level ground smoothly.
Comfort, Visibility & Technology 5
8-Inch Color Monitor
The standard LCD displays operating history, flow settings, service information and camera video in a clear interface.
Side and Rearview Cameras
Standard camera views help cover blind spots, while split-screen mode keeps machine information visible alongside the video.
Heated Air-Suspension Seat
The standard seat includes height and weight adjustment, a headrest, armrests and recline; cooling is optional.
Automatic Climate Control
High-performance heating and air conditioning support operator comfort through changing seasons and long shifts.
MY DEVELON Fleet Management
Standard telematics lets owners remotely monitor machine location, health, utilization and maintenance information.
Durability & Serviceability 5
D-Type Frame & X-Chassis
A reinforced frame and durable X-chassis add strength, minimize distortion and support long machine life.
Strengthened Boom & Arm
The reinforced working group is designed to withstand repeated digging, lifting and attachment loads.
Low-Wear Bucket Pivot
A polymer shim at the bucket pivot helps reduce wear and retain grease for smoother, longer-lasting operation.
Centralized Grease Points
Grouped boom and arm grease points and extended greasing intervals simplify routine maintenance.
Accessible Service Components
The oil filter, air cleaner, fuel filter, radiators and other engine components are arranged for convenient access.
Why Buyers Choose the DX170LC-7
Transport-friendly 38,360 lb operating weight and 8 ft 6 in width
115 net hp and 391 lb-ft of gross engine torque
20 ft 2.9 in dig depth and 29 ft 1.5 in ground-level reach
Dual 40.2 gpm pumps with available two-way auxiliary hydraulics
Four power modes, four work modes and Smart Power Control
27,778 lbf bucket force and 18,519 lbf arm force
Heated air-suspension seat plus side and rearview cameras
Durable X-chassis, reinforced workgroup and simplified maintenance
Who Uses the DX170LC-7 and What For
The DX170LC-7 is designed for contractors who need productive crawler-excavator reach and hydraulic performance in a lighter, narrow machine that is easier to move between jobs.
Residential Construction
- Basement and foundation excavation
- Home-site preparation
- Drainage and septic work
- Backfilling and finish grading
Landscaping
- Large landscape installations
- Pond and water-feature excavation
- Retaining-wall construction
- Land shaping and clearing
Utilities
- Water, sewer and storm trenching
- Service and drainage installation
- Manhole and structure placement
- Roadside repair work
Site Development
- Light commercial excavation
- Loading trucks and moving spoil
- Breaker and hydraulic attachment work
- Precise placement and leveling
The DX170LC-7 by the Numbers
DEVELON D34 net output at 2,000 rpm.
A transport-friendly 17.4-metric-ton configuration.
Paired with 29 ft 1.5 in of reach at ground level.
A narrow transport profile for moving between jobs.
Strong digging performance for light and general excavation.
Dual pumps support combined functions and hydraulic attachments.
Talk to a person about the DX170LC-7
Carleton Equipment is a family-owned Michigan dealer, here since 1938. Sales, rental, service and parts all come from the same team, and we’ll connect you with the location nearest you.
- Chesterfield
- Coldwater
- Grand Rapids
- Howell
- Kalamazoo
- Livonia
- Saginaw
Full Specifications
Download Spec SheetGeneral
| Machine Type | Crawler excavator |
| Operating Weight | 38,360 lbs |
| Ground Pressure | 5.8 psi |
| Standard Bucket | 0.99 yd³ |
| Standard Boom | 16 ft 8.8 in |
| Standard Arm | 8 ft 2.4 in |
| Counterweight | 5,732 lbs |
Engine
| Engine | DEVELON D34 |
| Displacement | 3.4 L |
| Cylinders | 4 |
| Net Power | 115 hp @ 2,000 rpm |
| Gross Power | 135 hp @ 2,000 rpm |
| Maximum Torque | 391 lb-ft @ 1,400 rpm |
| Emissions | Tier 4 Final; CEGR + DOC + SCR |
| Alternator | 24 V, 100 A |
| Battery | 2 × 12 V, 100 Ah |
Performance
| Maximum Digging Depth | 20 ft 2.9 in |
| Maximum Reach | 29 ft 8.3 in |
| Maximum Reach at Ground | 29 ft 1.5 in |
| Maximum Loading Height | 21 ft 0.8 in |
| Maximum Digging Height | 29 ft 10.1 in |
| Maximum Vertical Wall Depth | 13 ft 10 in |
| Maximum Vertical Radius | 22 ft 2 in |
| Maximum Depth to 8-Foot Line | 19 ft 6.3 in |
| Bucket Digging Force | 27,778 lbf |
| Arm Digging Force | 18,519 lbf |
| Maximum Swing Torque | 46,614 lbf·ft |
| Swing Speed | 0–10.3 rpm |
| Travel Speed | 1.9–3.1 mph |
| Maximum Traction Force | 45,195 lbf |
| Gradeability | 35° / 70% |
Hydraulics
| Main Pumps | 2 variable-displacement axial-piston pumps |
| Main Pump Flow | 2 × 40.2 gpm |
| Pilot Pump Flow | 7.9 gpm |
| Normal Implement Pressure | 4,694 psi |
| Power-Boost Pressure | 4,978 psi |
| Travel Pressure | 4,978 psi |
| Swing Pressure | 3,911 psi |
| Pilot Pressure | 555 psi |
Capacities
| Fuel Tank | 76.0 gal |
| DEF Tank | 7.9 gal |
| Cooling System | 7.2 gal |
| Engine Oil With Filter | 3.3 gal |
| Swing Drive | 0.8 gal |
| Final Drive, Each Side | 0.8 gal |
| Hydraulic System | 55.5 gal |
| Hydraulic Tank | 32.0 gal |
Dimensions
| Tail Swing Radius | 8 ft 3.6 in |
| Tail Swing Overhang, Rear | 1 ft 7.5 in |
| Tail Swing Overhang, Side | 4 ft 0.6 in |
| Shipping Length | 28 ft 1.4 in |
| Shipping Width | 8 ft 6 in |
| Shipping Height, Boom | 9 ft 2 in |
| Shipping Height, Hose | 9 ft 9.5 in |
| Cabin Height | 9 ft 8.5 in |
| Upper Structure Width | 8 ft 4 in |
| Overall Track Length | 13 ft 4.1 in |
| Undercarriage Width | 8 ft 6 in |
| Track Gauge Width | 6 ft 6.3 in |
| Standard Track Shoe Width | 23.6 in |
| Car Body Clearance | 1 ft 5.1 in |
Operator Environment
| Exterior Sound Level | 102 dB(A) |
| Cab Sound Level | 68 dB(A) |
| Display | 8-inch color LCD |
| Climate Control | Automatic heating and air conditioning |
| Seat | Heated air suspension |
| Side and Rearview Cameras | Standard |
Features
| Power Modes | P+ / P / S / E |
| Work Modes | Digging / Lifting / Breaker / Shear |
| Smart Power Control | Standard |
| Auto Idle and Auto Shutdown | Standard |
| Auxiliary Hydraulic Presets | 10 |
| MY DEVELON Fleet Management | Standard |
| Heated and Cooled Seat | Optional |
Values are from the current DEVELON North America DX170LC-7 product page and official sales specifications for the standard-arm US20 configuration. Specifications vary by attachment and track configuration. Contact Carleton Equipment to confirm details.
