You never stop pushing. And neither does DEVELON. Our rugged new dozer was intentionally designed around your needs: delivering best-in-class gross and net horsepower, superior visibility, easier operation, advanced technologies and lower total cost of ownership.
More features are standard with the DEVELON dozer, including fully electronic hydraulic controls, a rearview camera, heating and air conditioning system, LED lights and a DEVELON Smart Touch display.
The 6-way variable-angle pitch dozer blade provides more precision when moving or grading dirt, clay and other materials from nearly any angle to reduce the number of passes on each job. The dozer blade moves freely to lift, tilt and angle, and you can change the blade pitch using the 2-way mechanical adjustment.
Grading is easier using the 2D blade assist option, even for novice operators. Program the needed inputs, and the machine controls blade functions — finishing the job faster and more accurately. No GPS or lasers required.
Select the blade float function for smooth back grading or fine finishing. Push the blade shake button to quickly remove stuck-on materials.
The 6-way power-tilt angle blade provides more precision pushing capabilities to move and grade dirt, clay and other difficult material. Work more efficiently and reduce the number of passes on each job by lifting, tilting and angling the blade to move dirt or other materials exactly where they need to go.
A 2-way mechanical adjustment also allows you to adjust the blade pitch to control how steeply it bites into the ground. The DD100 dozer blade pitch adjusts from 54 — 58 degrees. The DD130 dozer blade pitch adjusts from 52 — 58 degrees. See page 19 for details.
For smooth back grading or fine finishing, select the blade float function to enable the blade to move up and down following the contours of the ground.
When grading mucky, clay-like material, use the blade shake button to activate a shaking motion to quickly remove material stuck to the blade — without leaving the cab.
The unique undercarriage system, with both single- and dual-flange rollers, is designed for convenient, cost-effective maintenance. Areas of the undercarriage that naturally experience greater wear and tear are easy to access. You can get affordable replacement parts through your local DEVELON dealer.
Regular inspection points for the dozer are conveniently accessible at ground level. When maintenance is needed, the dozer cabin tilts up — there’s no need to disassemble the cab to reach critical components.
General-purpose and full-guard track guard options are available for exceptional performance and uptime protection.
The narrow design of the front nose hood makes it easier to see your work. The cooling system for the radiator/oil cooler module is hydraulically driven and located at the rear of the machine.
Dozer engines deliver the robust power and durability required to take on the most demanding jobs. They’re optimized for more power output with reduced fuel consumption and feature Tier 4-compliant diesel engines to reduce emissions.
The DD100 DEVELON D34 diesel engine does not require the use of a diesel particulate filter (DPF) to meet current emissions standards.
To further improve fuel efficiency without sacrificing grading performance, select the ECO mode for light grading conditions and reduce daily fuel consumption up to 5%. The fuel-saving feature lowers the pump power output when working in lower tractive conditions.
To reduce noise, enable job site conversations and reduce fuel consumption, the auto idle feature idles the dozer engine automatically when machine functions are not used. Idle time can be set directly from the display monitor. Move the controls and the dozer will automatically return to your previous throttle setting.
The auto shutdown feature also saves fuel and helps lower warranty hours. When enabled, the engine shuts down after it has been idling for a specified amount of time. Default shutdown occurs after five minutes of idling, but can be set for longer periods using the Smart Touch display.
DEVELON dozers are designed to meet the needs of operators of every skill level. Electrohydraulic controls are standard, making the machines easier to operate — even for inexperienced crew members. The ergonomically designed joystick offers low-effort control to help reduce operator fatigue.
The DEVELON dozer cab layout and controls are similar to the DEVELON -7 Series excavators and wheel loaders, making operators more productive as they move from machine to machine throughout the workday.
The user-friendly, multilingual Smart Touch screen — a standard feature — displays all important settings and information on one screen. From the easy-to-read touch screen, operators can monitor critical dozer functions and control machine settings, rearview camera, heating and cooling, radio, Bluetooth® wireless technology and more.
This optional 2D grading system makes precision grading easier for novice operators. The operator programs the needed inputs, and the machine controls blade functions — finishing the job faster and with better accuracy. No GPS or lasers required.
For greater accuracy and ease of operation, this system can be added to the DD100 model. It reduces operator inputs by up to 80%, activating automatic blade movements based on GPS coordinates to meet critical elevation and slope specifications.
DEVELON developed a unique dozer undercarriage system to help lower the total cost of operation. The undercarriage features sealed and lubricated components, as well as single-and dual-flange rollers, to improve durability and extend component life.
Dual-flange rollers go outside the chain of the track, and single-flange rollers sit inside the chain of the track. The combination helps ensure that the track stays on the undercarriage, helping to reduce wear and providing greater operator comfort.
Areas of the undercarriage that naturally experience greater wear and tear are easy to access.
The oscillating serrated track system, standard on the DD130, ensures consistent, stable ground contact to improve fine grading performance and operator comfort. The system follows the terrain and enables more precise blade control.
