General Info
|
|
|---|---|
| Condition: | New |
| Manufacturer: | Iron Mode |
| Model: | PALLET FRAME 5K |
| Machine Type: | Other |
| Year: | 2022 |
| Stock Number: | 58343 |
|
Engine
|
|---|
|
Performance
|
|---|
|
Hydraulics
|
|---|
|
Dimensions
|
|---|
Description
The 2022 Iron Mode PALLET FRAME 5K is an essential addition to your heavy-duty equipment lineup. Designed specifically for contractors and industrial applications, this pallet frame allows for efficient handling and transportation of materials, ensuring that your operations run smoothly and effectively. With its robust construction and innovative walk-through design, you can easily maneuver in tight spaces while maximizing your productivity.
Located in Byron Center, MI, this new BC Pallet Frame Heavy Duty is built to withstand the rigors of daily use, making it an ideal choice for demanding job sites. Whether you're lifting heavy loads or managing materials with precision, the Iron Mode PALLET FRAME 5K offers the reliability and performance you need to get the job done right. Elevate your equipment capabilities with this exceptional pallet frame and experience the difference in your workflow.
Compare the Small Air Compressors
 |
 |
 |
 |
|
| PA185 | PA185V | PA185VP | PA250V | |
|---|---|---|---|---|
| Compressed Air | ||||
| Free Air Delivery (FAD) | 185 cfm (5.2 m³/min) | 185 cfm (5.2 m³/min) | 185 cfm (5.2 m³/min) | 250 cfm (7.0 m³/min) |
| Rated Operating Pressure | 100 psig (6.9 bar) | 100 psig (6.9 bar) | 125 psig (8.6 bar) | 100 psig (6.9 bar) |
| Pressure Range | 80–100 psig | 80–150 psig (5.5–10.3 bar) | 80–200 psig (5.5–13.7 bar) | 80–175 psig (5.5–12.0 bar) |
| FlexAir Flow Range | — | 184–150 cfm (5.2–4.2 m³/min) | 184–165 cfm (5.2–4.7 m³/min) | 249–185 cfm (7.0–5.2 m³/min) |
| Air Service Outlets | 2 × 0.75 in (19 mm) | 2 × 0.75 in (19 mm) | 2 × 0.75 in (19 mm) | 2 × 0.75 in (19 mm) |
| Fuel Tank Capacity | 34.5 gal (130.6 L) | 34.5 gal (130.6 L) | 34.5 gal (130.6 L) | 34.5 gal (130.6 L) |
| Engine | ||||
| Make & Model | Doosan D18 | Doosan D24 | Doosan D24 | Doosan D24 |
| Bhp @ Rated Speed | 49.0 bhp (36.6 kW) | 49.0 bhp (36.6 kW) | 74.0 bhp (55.2 kW) | 74.0 bhp (55.2 kW) |
| Cylinders | 3 | 4 | 4 | 4 |
| Displacement | 110 cu in (1.8 L) | 147 cu in (2.4 L) | 147 cu in (2.4 L) | 147 cu in (2.4 L) |
| Emissions | Tier 4 Final | Tier 4 Final | Tier 4 Final | Tier 4 Final |
| Runtime @ Full Load | 12.6 hr | 12.2 hr | 11.0 hr | 8.7 hr |
| Dimensions & Weight (Enclosed) | ||||
| Working Weight (w/ fuel) | 2,359 lbs | 2,477 lbs | 2,594 lbs | 2,594 lbs |
| Length | 137.4 in | 137.4 in | 142.9 in | 142.9 in |
| Width | 68.5 in | 68.5 in | 68.5 in | 68.5 in |
| Height | 67.5 in | 67.5 in | 67.5 in | 67.7 in |
FlexAir variable flow & pressure is available on the V / VP / 250V models; the PA185 is the fixed-output base unit. Dimensions and weights shown are for the enclosed unit (working weight includes fuel).
Bobcat Air Compressor Technology
Precision Rotors
The rotors used in Bobcat proprietary airends feature a versatile gearbox design with case carburized gears, providing a wide gear ratio range. Premium bearings also add greater durability and improve operational efficiency.
FlexAir System
Bobcat compressors, featuring the variable FlexAir System, let you maintain complete control of both air pressure and airflow. From the control panel, you can dial in the exact combination of pressure and flow within the compressor's operational range.
Dual Pressure Capability
Dual pressure compressors offer two-in-one versatility with clear HI/LOW options on the control panel. Operators can select between two adjustable airflow and air pressure combinations to power multiple applications, eliminating the need for multiple compressors.
Proprietary Airends
With tighter rotor tolerances comes better performance. Bobcat proprietary airends are engineered to deliver exceptional performance, low vibration and reduced noise, and they're manufactured at our state-of-the-art facility in Statesville, North Carolina.
|
