Wrangler Dump Trailer | Watchdog
A lighter trailer for more towing vehicles but engineered for maximum strength in frame and dump body. The Wrangler might be bare bones but comes with all the essentials and purely exists to get work done.
Specs:
-
Bed Length Options:
- 14'
-
Side Wall Heights:
- 2'
-
GVWR Options:
- 14,000 lbs
Features:
- 3 Stage Telescopic Lift
- Toolbox w/Charger
- 7k Drop Leg Jack
- 6 Position Adjustable Coupler
- 6" Channel Frame
- Side Steps
- 9/16" Axle Studs
- Tandem 7,000 lbs Axles w/ Electric Brakes
- Formed Rear Out Ramps
- Barndoor/Spreader Gates
- (5) D-Rings
- Stake Pockets
- Spare Tire Mounts
| Wrangle Dump Trailer | Standard Features |
|---|---|
| Frame | 6" C-channel |
| Crossmembers | 6"x2" Formed C-channel |
| Sidewalls | 24" 10Ga |
| Floor | 10Ga |
| Doors | Barndoor/Spreader Combo, w/ Slam Latch |
| Storage | Tongue Mounted Toolbox |
| Tie-downs | (5) D-rings and Stake Pockets |
| Ramps | Rear Slide-out, Formed, w/ Traction Holes and Tabs |
| Coupler | 6 Position Adjustable Coupler |
| Jack | 7k Drop Leg |
| Toolbox | Tongue Mounted Toolbox |
| Tarp | Optional Tarp w/ Anti-Sail Bar |
| Battery Charger | 8hr Charger with External AC Port and Battery Level Monitor |
| Battery | 12v Deep Cycle |
| Wiring | 7way Connector with Molded Wiring Harness |
| Hydraulics | 3 Stage Telescopic |
| Fenders | 500lb Rated |
| Axles | Tandem 7,000# Axles w/ Champhered Spindle for Better Tracking Tolerance |
| Brakes | Self-Adjusting Electric Brakes |
| Suspension | Multi-leaf Slipper Spring w/ Equalizer and Wet Bolt |
| Tires | 235/80/R16, Load Range E, 10ply |
| Spare Tire | Not Standard |
| Spare Mount | Curb Side |
| Powercoat | Mount Standard Gloss Black or Battleship Grey |
