T86 | Bobcat

R-Series
Bobcat

Rebates & Special Offers

View Full Offer

Get as low as 0% for 60 months* or $15,000 cash rebate* in lieu of financing.

Download Spec Sheet

Get detailed specifications, dimensions, and performance data for this T86 | Bobcat.

Download Spec Sheet →
Horsepower
105 hp
Rated operating capacity
3,800 lb
Operating weight
12,393 lb
Hinge pin height
132 in
See full specifications
More specifications
General Info
Condition: Showroom
Manufacturer: Bobcat
Model: T86
Machine Type: Compact Track Loader
Coupler: Bob-Tach
Engine
Horsepower: 105.0
Emissions: Tier 4
Performance
Rated Operating Capacity (ISO): 3,800 lb
Tipping Load: 10,857 lb
Operating Weight: 12393 lb
Height to Bucket Hinge Pin: 132 IN.
Hydraulics
Aux. Standard Flow: 23.6 GPM
Aux. High Flow: 36.6 GPM
Aux. Super High Flow: 42 GPM
Dimensions
Height: 83.1 IN.
Width: 80 IN.
Fuel Tank: 31.6 GAL.

Description

Bobcat T86 Compact Track Loader

The Bobcat T86 is one of the most powerful compact loaders Bobcat has ever built. Delivering more usable engine & hydraulic horsepower than ever before! Greater lifting capabilities, impressive breakout forces, & leading maneuverability for fast cycle times are just a few of the improvements.

  • Optional high-flow and super-flow hydraulics
  • 105-hp, Tier 4 engine
  • Leading attachment versatility
  • Premium Power Performance system for greater productivity
  • Premium comfort

Hydraulic Flows

The Bobcat T86 delivers three hydraulic flow options giving you the versatility you need for any job!

  • Standard Flow | 23 GPM / 3,500 PSI
  • High Flow | 36.6 GPM / 3,500 PSI
  • Super Flow | 42 GPM / 4,061 PSI

Specs

Rated Operating Capacity 3,800 lb
Operating Weight 12,393 in
Ground Pressure - Rubber Track 4.8 psi
Auxiliary Standard Flow 23.6 gal/min
Auxiliary High Flow 36.6 gal/min
Emissions Tier Tier 4
Engine Fuel Diesel
Horsepower 105 hp
Turbocharged Engine Yes
Rated Operating Capacity 3,800 lb
Rated Operating Capacity - 200 lb Counterweight 3,950 lb
Rated Operating Capacity - 300 lb Counterweight 4,025 lb
Rated Operating Capacity - 400 lb Counterweight 4,100 lb
Operating Capacity - 50% of Tip 5,429 lb
Tipping Load 10,857 lb
Operating Weight 12,393 lb
Travel Speed 5.5 mph
Travel Speed - 2 Speed Option 10.7 mph
Ground Pressure 4.8 psi
Auxiliary Standard Flow 23.6 GPM
Auxiliary High Flow 36.6 GPM
Auxiliary Super Flow 42 GPM
System Relief @ Quick Couplers 3,450 PSI
Length 120.4 in
Width 78 in
Width with Bucket 80 in
Height 83.1 in
Height to Bucket Hinge Pin 132 in
Reach @ Maximum Height 38.4 in
Length of Track on Ground 66.3 in
Track Width 17.7 in

Features

If you frequently place pallets of blocks or sod, or dump into high-sided trucks, a vertical lift path may be the best choice. On vertical-lift-path loaders, the load is raised straight up, closer to the machine. You can safely lift more than an identical radius-lift-path machine. Since you have more reach at full lift height, you dump into the center of the truck — or keep the loader farther away, depending on your needs.Bobcat Vertical Lift Path
The Bobcat® T86 compact track loader and S86 skid-steer loader are the only compact loaders to offer standard-flow, high-flow and super-flow auxiliary hydraulics in one machine. Learn more about the optional super-flow advantage and how these compact loaders set a new industry benchmark in attachment versatility and performance.
0%
for up to 60 months*
Financing Available
OR
$15,000USD*
cash rebate in lieu of financing
Customer Rebate

See participating dealers for details.

*Program disclosure: 0% A.P.R. financing for up to 60 months and $15,000 USD customer rebate offers are mutually exclusive — select one or the other. Financing subject to credit approval through an authorized Bobcat financing provider. Offer applied at time of purchase. Offers valid on qualifying new Bobcat compact track loader models through participating dealers only. See dealer for complete details, eligibility requirements, and program end dates. Offers subject to change without notice.

T86 Key Features

What Makes the T86 Different

Three Hydraulic Flow Options

The T86 offers 23.6 gpm standard flow, optional 36.6 gpm high flow and optional 42 gpm super flow at 4,061 psi, giving you the versatility you need for any job.

Super-Flow Auxiliary Hydraulics

The Bobcat T86 compact track loader and S86 skid-steer loader are the only compact loaders to offer standard-flow, high-flow and super-flow auxiliary hydraulics in one machine, setting a new industry benchmark in attachment versatility and performance.

105 HP Tier 4 Engine

A 105 hp Tier 4 diesel engine delivers more usable engine and hydraulic horsepower than any Bobcat compact loader before it.

Premium Power Performance System

The Premium Power Performance system pairs greater lifting capabilities and impressive breakout forces with leading maneuverability for fast cycle times and greater productivity.

Vertical Lift Path

On a vertical-lift-path loader the load is raised straight up, closer to the machine, so you can safely lift more than an identical radius-lift-path machine and dump into the center of high-sided trucks.

Counterweight Capacity Options

Optional 200 lb, 300 lb and 400 lb counterweights raise rated operating capacity from 3,800 lb to 3,950 lb, 4,025 lb or 4,100 lb.

Compare the Family

Bobcat Compact Track Loaders

Bobcat T450 compact track loader
T550
 Bobcat T595 compact track loader
T62
 Bobcat T64-2 compact track loader Bobcat T66-2 compact track loader Bobcat T7X all-electric compact track loader Bobcat T650 compact track loader
T740
 Bobcat T770 compact track loader Bobcat T76-2 compact track loader Bobcat T86-2 compact track loader
T450 T550 T595 T62 T64-2 T66-2 T7X T650 T740 T770 T76-2 T86Viewing
Frame / RoleCompact classicMid-size classicCurrent classicNon-current mid-frameMid-frameMid-frameAll-electricLarger classicLarge classicLargest classicLarge-frameHigh-output large-frame
Horsepower55 hp68 hp70 hp68 hp68 hp74 hp100 hp74 hp74 hp92 hp74 hp105 hp
Rated Operating Capacity1,490 lbs1,995 lbs2,100 lbs2,150 lbs2,300 lbs2,400 lbs3,056 lbs2,500 lbs3,200 lbs3,475 lbs2,900 lbs3,800 lbs
Tipping Load4,257 lbs5,700 lbs6,000 lbs6,143 lbs6,571 lbs6,857 lbs8,743 lbs7,143 lbs9,143 lbs9,929 lbs8,285 lbs10,857 lbs
Operating Weight6,424 lbs7,557 lbs7,906 lbs8,612 lbs8,440 lbs8,560 lbs12,590 lbs8,980 lbs10,127 lbs10,515 lbs9,592 lbs12,393 lbs
Travel Speed7 / 11 mph7.1 / 10.4 mph7.1 / 10.4 mph7.2 mph6.4 / 9.3 mph5.5 / 9.3 mph5.7 / 8.7 mph6 / 8.7 mph6 / 8.3 mph6.6 / 10.7 mph6.8 / 9.2 mph5.5 / 10.7 mph
Standard Aux Flow16.7 gpm17.1 gpm17.1 gpm17.6 gpm17.6 gpm17.6 gpmNo hydraulics23 gpm23 gpm23 gpm23.3 gpm23.6 gpm
High / Super Flow—26.7 gpm26.7 gpm26.9 gpm26.9 gpm26.9 gpm—30.5 gpm30.5 gpm36.6 gpm30.3 gpm36.6 / 42 gpm
Height to Hinge Pin109.5 in114.5 in119 in114.5 in120 in120 in128.4 in124 in132 in132 in128.3 in132 in
Overall Width55 in67 in66.6 in67 in67.8 in67.8 in78 in72.9 in78 in78 in73.5 in78 in

Specs are model-level published values. Confirm final configuration, options and current availability with your Carleton Equipment location.

Request a Quote View All Track Loaders Find a Local Dealer
T86

T86 Features & Benefits

Performance
Maximum R-Series Output

The Bobcat T86 delivers 105 hp with a 3,800 lb rated operating capacity, 10,857 lb tipping load and 12,393 lb operating weight, making it one of the most powerful compact loaders Bobcat has ever built.

11-Foot Lift Height

A 132 in hinge-pin height and 38.4 in reach at maximum height support truck loading, elevated placement and high-production material handling.

Two-Speed Travel

Travel speed is 5.5 mph in low range, and the two-speed option raises top travel speed to 10.7 mph for faster moves across larger jobsites.

Hydraulics & Attachments
Three Flow Options

Standard flow is 23.6 gpm at 3,500 psi, optional high flow is 36.6 gpm at 3,500 psi, and optional super flow is 42 gpm at 4,061 psi for the most demanding attachments.

Super-Flow Exclusivity

The T86 and its S86 skid-steer sibling are the only compact loaders to offer standard, high and super flow in one machine.

Leading Attachment Versatility

The Bob-Tach attachment system and three flow levels connect the T86 to the widest range of Bobcat loader attachments.

Productivity & Comfort
Premium Power Performance System

Greater lifting capabilities, impressive breakout forces and leading maneuverability combine for fast cycle times and greater productivity.

Premium Comfort

Premium comfort is one of the headline improvements on the T86, helping operators stay productive through long shifts.

Counterweight Options

Optional 200 lb, 300 lb and 400 lb counterweights raise rated operating capacity to 3,950 lb, 4,025 lb or 4,100 lb for heavier loads.

Traction & Support
Low Ground Pressure

With 4.8 psi ground pressure on 17.7 in rubber tracks and 66.3 in of track on the ground, the T86 spreads its weight for flotation on soft or unfinished ground.

Tier 4 Diesel Engine

The turbocharged 105 hp diesel engine meets Tier 4 emissions requirements.

Bobcat Dealer Support

Carleton Equipment supports the T86 with Bobcat parts, service, attachments and local product knowledge across Michigan.

Bobcat T86 Compact Track Loader

Why Buyers Choose the T86

105 hp, 3,800 lb ROC and 10,857 lb tipping load support high-demand work in a compact track loader footprint

Three hydraulic flow options include 23.6 gpm standard, 36.6 gpm high flow and 42 gpm super flow for demanding attachments

132 in hinge-pin height and 38.4 in reach help with truck loading, elevated placement and production material handling

Two-speed travel reaches up to 10.7 mph for faster movement across larger jobsites

Optional counterweights raise rated operating capacity up to 4,100 lb

Premium Power Performance system and a vertical lift path deliver strong breakout forces and fast cycle times

Customers & Applications

Who Uses the T86 and What For

The T86 is a high-output R-Series compact track loader for crews that need maximum hydraulic flow, strong lift capacity and track-loader traction for demanding jobsites.

Construction & Demolition

  • Digging, loading, grading, backfilling and site cleanup
  • Moving pallets, aggregate, spoil, concrete and demolition debris
  • Running breakers, planers, wheel saws, buckets, forks and grapples
  • Working where lift height, hydraulic power and traction all matter

Forestry & Land Management

  • Running high-demand attachments such as drum mulchers and stump grinders on super flow
  • Clearing brush, maintaining trails and preparing undeveloped sites
  • Operating on rough, soft or unfinished terrain where tracks help flotation
  • Adding counterweight for heavier material-handling loads

Fleet & Specialty Contractors

  • Proven R-Series platform with dealer parts and service support
  • Three flow options cover a demanding attachment fleet from one machine
  • Bob-Tach coupler keeps the loader compatible with a broad attachment mix
  • Supported by Carleton Equipment parts, service and attachment expertise
Compact Track Loaders

Two Paths: Classic or Pro

Not sure which tier fits your application? Compare the full CTL lineup side by side.

Explore the Lineup
Pro Loader Packages

Find the Right Package for the Way You Work

Package options make it easier to choose the right mix of advanced comfort, control and technology for the way you work. Compare package levels below to find the Pro Bobcat loader setup that matches your jobsites, applications and operator preferences.

Request a Quote Download Full Package Guide

WORK, CORE, PLUS and ADVANCED packages are available across Pro Bobcat loaders.

Work Core Plus Advanced
Overview
Summary Pro control and operation at a competitive price. Pro control and operation with upgraded comfort and performance options. Pro control and operation with premium comfort and performance standard. Plus package with Jobsite Companion.
Standard Features
Power Bob-Tach® ✔ ✔ ✔ ✔
Keyless Ignition ✔ ✔ ✔ ✔
7-Pin Attachment Control ✔ ✔ ✔ ✔
2-Speed ✔ ✔ ✔ ✔
Auto-Throttle ✔ ✔ ✔ ✔
Dual-Direction Bucket Positioning ✔ ✔ ✔ ✔
Bluetooth Radio ✔ ✔ ✔ ✔
Main Package Differences
Suspension Seat Vinyl High-Back Heated Cloth Air-RideWith Enclosed Cab High-Back Heated Cloth Air-Ride High-Back Heated Cloth Air-Ride
Display 8" 8" w/ InfotainmentWith Enclosed Cab 8" w/ Infotainment 8" w/ Infotainment
Lights LED Premium LED Premium LED w/ Side Lights Premium LED w/ Side Lights
Machine IQ Telematics 2YR Basics 2YR Basics 1YR H&S + 1YR Basics 1YR H&S + 1YR Basics
Automatic Ride Control — ✔ ✔ ✔
Sound Reduction — ✔With Enclosed Cab ✔ ✔
Jobsite Companion — — — ✔
Package Options
Cab Open or Enclosed HVAC Open or Enclosed HVAC Enclosed HVAC W/ Clear-Side Enclosure Enclosed HVAC W/ Clear-Side Enclosure
Controls SJC STD
Hand & Foot OPT		 SJC STD
Hand & Foot OPT		 SJC STD
Hand & Foot OPT		 SJC
Camera(s) Rear View Rear View Rear View STD
Broad Area OPT		 Rear View STD
Broad Area OPT
Undercarriage Solid Mount Solid Mount Solid Mount Solid Mount
Auxiliary Flow Standard Flow Standard Flow STD
Standard+High OPT		 Standard+High STD Standard+High STD
Reversing Fan — Included w/ High Flow ✔ ✔
Bobcat Sense Rear Object Detection and Avoidance OPT Rear Object Detection and Avoidance OPT Rear Object Detection and Avoidance OPT 360 People Detection OPT
Tracks C-Pattern 12.6" STD
C-Pattern 15.7" OPT
MBL 15.7" OPT		 C-Pattern 12.6" STD
C-Pattern 15.7" OPT
MBL 15.7" OPT		 C-Pattern 12.6" STD
C-Pattern 15.7" OPT
MBL 15.7" OPT		 C-Pattern 12.6" STD
C-Pattern 15.7" OPT
MBL 15.7" OPT
STD Included standard OPT Available as an add-on "With Enclosed Cab" — feature level varies based on cab selection

Talk to a person about the T86

Carleton Equipment is a family-owned Michigan dealer, here since 1938. Sales, rental, service and parts all come from the same team, and we’ll connect you with the location nearest you.

  • Chesterfield
  • Coldwater
  • Grand Rapids
  • Howell
  • Kalamazoo
  • Livonia
  • Saginaw
Call any location, toll-free 1-888-380-6420
Request a Quote Find your nearest location

Full Specifications

Download Spec Sheet
General
ConditionShowroom
Machine TypeCompact Track Loader
Engine
Engine MakeBobcat
Horsepower105.0
EmissionsTier 4
Performance
ROC Solid Undercarriage3,800 lb
Bucket Hinge Pin Height132 IN.
Tipping Load10,857 lb
Capacities
Fuel Tank31.6 GAL.
Hydraulics
Auxiliary Std Flow23.6 GPM
Auxiliary High Flow36.6 GPM
Aux. Super High Flow42 GPM
Dimensions & Weight
Height83.1 IN.
Width80 IN.
Operating Weight12393 lb
Serviceability

Specifications subject to change without notice. Contact your local Carleton Equipment dealer to confirm details.
