Rebates & Special Offers
View Full OfferGet as low as 0% for 60 months* or $15,000 cash rebate* in lieu of financing.
- Horsepower
- 74 hp
- Rated operating capacity
- 2,450 lb
- Operating weight
- 8,927 lb
- Hinge pin height
- 120 in
More specifications
|
General Info
|
|
|---|---|
| Condition: | Showroom |
| Manufacturer: | Bobcat |
| Model: | T66 |
| Machine Type: | Compact Track Loader |
| Coupler: | Bob-Tach |
|
Engine
|
|
|---|---|
| Horsepower: | 74.0 |
| Emissions: | Tier 4 |
|
Performance
|
|
|---|---|
| Rated Operating Capacity (ISO): | 2,450 lb |
| Operating Weight: | 8927 lb |
| Height to Bucket Hinge Pin: | 120 IN. |
|
Hydraulics
|
|
|---|---|
| Aux. Standard Flow: | 17.6 GPM |
| Aux. High Flow: | 26.9 GPM |
|
Dimensions
|
|
|---|---|
| Width: | 67 IN. |
| Fuel Tank: | 28.3 GAL. |
Description
Bobcat® T66 Compact Track Loader
Description
No matter how extreme your working conditions, the vertical-lift-path Bobcat® T66 compact track loader pushes through to do more in all kinds of applications and keeps working where other equipment can’t. Also referred to as a skid-steer with tracks, the T66 includes a redesigned Bobcat inline engine and direct-drive system, lift arms with cast-steel construction and improved cooling performance. This 74-hp loader offers a Rated Operating Capacity of 2450 lbs, and delivers powerful hydraulics and breakout forces, fast cycle times and increased lifting capabilities. Its roomier cab design offers a sealed and pressurized environment complete with available heated air-ride seat, clear-side enclosure, automatic heat and air conditioning, and an innovative display with machine information and performance data. Combine that with a superior 5-Link torsion suspension undercarriage for an unmatched operator experience to elevate productivity during long working hours.
Specs
Engine
| Emissions Tier (EPA) | Tier 4 |
| Engine Cooling | Liquid |
| Engine Fuel | Diesel |
| Horsepower | 74 hp |
| Turbocharged Engine |
Optional |
Performance
| Rated Operating Capacity (ISO) | 2,450 lb |
| Operating Capacity (50% of Tip) | 3,500 lb |
| Tipping Load | 7,000 lb |
| Operating Weight | 8,927 lb |
| Travel Speed | 7.2 mph |
| Travel Speed (2 - Speed Option) | 10.2 mph |
| Ground Pressure (Rubber) | 5.9 psi |
Capacities
| Fuel Tank | 28.3 gal |
Hydraulic System
| System Relief @ Quick Couplers | 3,500 psi |
| Auxiliary Std Flow | 17.6 gal/min |
| Auxiliary High Flow | 26.9 gal.min |
Dimension
| Length | 134.9 in |
| Length Without Attachment | 107 in |
| Length With Standard Bucket | 134.9 in |
| Width | 67 in |
| Width (With Bucket) | 68 in |
| Height | 80.5 in |
| Height With Operator Cab | 80.5 in |
| Height to Bucket Hinge Pin | 120 in |
| Reach @ Maximum Height | 36.7 in |
| Turning Radius | 81.5 in |
| Length of Track on Ground |
54.3 in |
| Track Width |
12.6 in |
| Track Width - Optional | 15.7 in |
What Makes the T66 Different
Inline Engine and Direct-Drive System
A redesigned 74 hp Bobcat inline engine and direct-drive system with improved cooling performance delivers powerful hydraulics, strong breakout forces and fast cycle times.
Cast-Steel Lift Arms
Lift arms with cast-steel construction support the T66's increased lifting capabilities and long-term durability on demanding jobsites.
5-Link Torsion Suspension Undercarriage
The 5-Link torsion suspension undercarriage delivers a smoother ride that helps elevate productivity during long working hours.
Sealed and Pressurized Cab
The roomier cab design offers a sealed and pressurized environment with a clear-side enclosure and automatic heat and air conditioning.
Heated Air-Ride Seat
An available heated air-ride seat helps operators stay comfortable through extreme working conditions and long days.
Machine Information Display
An innovative display puts machine information and performance data in front of the operator.
Bobcat Compact Track Loaders
 |
T550 |
 |
T62 |
 |
 |
 |
 |
T740 |
 |
 |
 |
|
| T450 | T550 | T595 | T62 | T64-2 | T66Viewing | T7X | T650 | T740 | T770 | T76-2 | T86-2 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Frame / Role | Compact classic | Mid-size classic | Current classic | Non-current mid-frame | Mid-frame | Mid-frame | All-electric | Larger classic | Large classic | Largest classic | Large-frame | High-output large-frame |
| Horsepower | 55 hp | 68 hp | 70 hp | 68 hp | 68 hp | 74 hp | 100 hp | 74 hp | 74 hp | 92 hp | 74 hp | 115 hp |
| Rated Operating Capacity | 1,490 lbs | 1,995 lbs | 2,100 lbs | 2,150 lbs | 2,300 lbs | 2,450 lbs | 3,056 lbs | 2,500 lbs | 3,200 lbs | 3,475 lbs | 2,900 lbs | 3,925 lbs |
| Tipping Load | 4,257 lbs | 5,700 lbs | 6,000 lbs | 6,143 lbs | 6,571 lbs | 7,000 lbs | 8,743 lbs | 7,143 lbs | 9,143 lbs | 9,929 lbs | 8,285 lbs | 11,214 lbs |
| Operating Weight | 6,424 lbs | 7,557 lbs | 7,906 lbs | 8,612 lbs | 8,440 lbs | 8,927 lbs | 12,590 lbs | 8,980 lbs | 10,127 lbs | 10,515 lbs | 9,592 lbs | 12,104 lbs |
| Travel Speed | 7 / 11 mph | 7.1 / 10.4 mph | 7.1 / 10.4 mph | 7.2 mph | 6.4 / 9.3 mph | 7.2 / 10.2 mph | 5.7 / 8.7 mph | 6 / 8.7 mph | 6 / 8.3 mph | 6.6 / 10.7 mph | 6.8 / 9.2 mph | 5.5 / 10.7 mph |
| Standard Aux Flow | 16.7 gpm | 17.1 gpm | 17.1 gpm | 17.6 gpm | 17.6 gpm | 17.6 gpm | No hydraulics | 23 gpm | 23 gpm | 23 gpm | 23.3 gpm | 23 gpm |
| High / Super Flow | — | 26.7 gpm | 26.7 gpm | 26.9 gpm | 26.9 gpm | 26.9 gpm | — | 30.5 gpm | 30.5 gpm | 36.6 gpm | 30.3 gpm | 36.6 / 42 gpm |
| Height to Hinge Pin | 109.5 in | 114.5 in | 119 in | 114.5 in | 120 in | 120 in | 128.4 in | 124 in | 132 in | 132 in | 128.3 in | 144 in |
| Overall Width | 55 in | 67 in | 66.6 in | 67 in | 67.8 in | 67 in | 78 in | 72.9 in | 78 in | 78 in | 73.5 in | 78 in |
Specs are model-level published values. Confirm final configuration, options and current availability with your Carleton Equipment location.
T66 Features & Benefits
Performance
74 HP R-Series CTL Power
The Bobcat T66 delivers 74 hp with a 2,450 lb rated operating capacity, 7,000 lb tipping load and 8,927 lb operating weight for all kinds of applications.
Vertical Lift Path
A 120 in hinge-pin height and 36.7 in reach at maximum height support truck loading, pallet placement and elevated attachment work.
High-Flow Hydraulics
Standard auxiliary flow is 17.6 gpm, with optional high flow of 26.9 gpm at 3,500 psi for higher-demand Bobcat attachments.
Comfort & Control
Roomier Sealed Cab
The roomier cab design offers a sealed and pressurized environment with a clear-side enclosure for visibility and protection from dust and weather.
Heated Air-Ride Seat and Climate Control
An available heated air-ride seat and automatic heat and air conditioning help reduce fatigue over long working hours.
Machine Information Display
An innovative display presents machine information and performance data so operators can keep track of the loader while they work.
Durability & Serviceability
Cast-Steel Lift Arms
Lift arms with cast-steel construction are built to stand up to extreme working conditions.
Improved Cooling Performance
The redesigned inline engine and direct-drive system come with improved cooling performance to keep working when conditions get extreme.
Bobcat Dealer Support
Carleton Equipment supports the T66 with Bobcat parts, service, attachments and local product knowledge across Michigan.
Traction & Versatility
5-Link Torsion Suspension Undercarriage
The 5-Link torsion suspension undercarriage smooths the ride over rough ground and helps the T66 keep working where other equipment cannot.
Track Flotation
With 5.9 psi ground pressure on 12.6 in rubber tracks, and an optional 15.7 in track width, the T66 pushes through soft or unfinished ground.
Two-Speed Travel Option
Standard travel speed is 7.2 mph, and the two-speed option raises top travel speed to 10.2 mph for faster moves across the jobsite.
Why Buyers Choose the T66
74 hp and 2,450 lb ROC for everyday loading, grading and attachment work
7,000 lb tipping load and 120 in hinge-pin height support truck loading and pallet placement
Optional high-flow hydraulics of 26.9 gpm expand attachment capability
5-Link torsion suspension undercarriage and 5.9 psi ground pressure for a smooth ride on soft ground
Sealed, pressurized cab with clear-side enclosure, automatic heat and A/C and available heated air-ride seat
Optional two-speed travel reaches up to 10.2 mph for faster jobsite movement
Who Uses the T66 and What For
The T66 is an R-Series compact track loader for crews that want strong rated operating capacity, a comfortable sealed cab and a suspension undercarriage that keeps working in extreme conditions.
Construction & Utility Work
- Grading, backfilling, trench support and site cleanup
- Moving aggregate, pallets, spoil, debris and jobsite materials
- Running augers, breakers, trenchers, buckets, forks and grapples
- Working where lift capacity and compact CTL flotation both matter
Landscape & Grounds Crews
- Preparing hardscape bases and spreading soil, stone or mulch
- Using soil conditioners, brush tools, grading attachments and snow tools
- Operating across soft turf, unfinished lots and uneven terrain
- Staying comfortable through long days with the sealed cab and suspension undercarriage
Rental & Fleet Owners
- Proven R-Series platform with dealer parts and service support
- Bob-Tach coupler keeps the loader compatible with a broad attachment mix
- Optional high flow supports a wider attachment rental mix
- Supported by Carleton Equipment parts, service and attachment expertise
Pro Loader Packages
Find the Right Package for the Way You Work
Find the Right Package for the Way You Work
Package options make it easier to choose the right mix of advanced comfort, control and technology for the way you work. Compare package levels below to find the Pro Bobcat loader setup that matches your jobsites, applications and operator preferences.
WORK, CORE, PLUS and ADVANCED packages are available across Pro Bobcat loaders.
| Work | Core | Plus | Advanced | |
|---|---|---|---|---|
| Overview | ||||
| Summary | Pro control and operation at a competitive price. | Pro control and operation with upgraded comfort and performance options. | Pro control and operation with premium comfort and performance standard. | Plus package with Jobsite Companion. |
| Standard Features | ||||
| Power Bob-Tach® | ✔ | ✔ | ✔ | ✔ |
| Keyless Ignition | ✔ | ✔ | ✔ | ✔ |
| 7-Pin Attachment Control | ✔ | ✔ | ✔ | ✔ |
| 2-Speed | ✔ | ✔ | ✔ | ✔ |
| Auto-Throttle | ✔ | ✔ | ✔ | ✔ |
| Dual-Direction Bucket Positioning | ✔ | ✔ | ✔ | ✔ |
| Bluetooth Radio | ✔ | ✔ | ✔ | ✔ |
| Main Package Differences | ||||
| Suspension Seat | Vinyl | High-Back Heated Cloth Air-RideWith Enclosed Cab | High-Back Heated Cloth Air-Ride | High-Back Heated Cloth Air-Ride |
| Display | 8" | 8" w/ InfotainmentWith Enclosed Cab | 8" w/ Infotainment | 8" w/ Infotainment |
| Lights | LED | Premium LED | Premium LED w/ Side Lights | Premium LED w/ Side Lights |
| Machine IQ Telematics | 2YR Basics | 2YR Basics | 1YR H&S + 1YR Basics | 1YR H&S + 1YR Basics |
| Automatic Ride Control | — | ✔ | ✔ | ✔ |
| Sound Reduction | — | ✔With Enclosed Cab | ✔ | ✔ |
| Jobsite Companion | — | — | — | ✔ |
| Package Options | ||||
| Cab | Open or Enclosed HVAC | Open or Enclosed HVAC | Enclosed HVAC W/ Clear-Side Enclosure | Enclosed HVAC W/ Clear-Side Enclosure |
| Controls | SJC STD Hand & Foot OPT |
SJC STD Hand & Foot OPT |
SJC STD Hand & Foot OPT |
SJC |
| Camera(s) | Rear View | Rear View | Rear View STD Broad Area OPT |
Rear View STD Broad Area OPT |
| Undercarriage | Solid Mount | Solid Mount | Solid Mount | Solid Mount |
| Auxiliary Flow | Standard Flow | Standard Flow STD Standard+High OPT |
Standard+High STD | Standard+High STD |
| Reversing Fan | — | Included w/ High Flow | ✔ | ✔ |
| Bobcat Sense | Rear Object Detection and Avoidance OPT | Rear Object Detection and Avoidance OPT | Rear Object Detection and Avoidance OPT | 360 People Detection OPT |
| Tracks | C-Pattern 12.6" STD C-Pattern 15.7" OPT MBL 15.7" OPT |
C-Pattern 12.6" STD C-Pattern 15.7" OPT MBL 15.7" OPT |
C-Pattern 12.6" STD C-Pattern 15.7" OPT MBL 15.7" OPT |
C-Pattern 12.6" STD C-Pattern 15.7" OPT MBL 15.7" OPT |
Talk to a person about the T66
Carleton Equipment is a family-owned Michigan dealer, here since 1938. Sales, rental, service and parts all come from the same team, and we’ll connect you with the location nearest you.
- Chesterfield
- Coldwater
- Grand Rapids
- Howell
- Kalamazoo
- Livonia
- Saginaw
Full Specifications
General
| Condition | Showroom |
| Machine Type | Compact Track Loader |
Engine
| Engine Make | Bobcat |
| Horsepower | 74.0 |
| Emissions | Tier 4 |
Performance
| ROC Solid Undercarriage | 2,450 lb |
| Bucket Hinge Pin Height | 120 IN. |
Capacities
| Fuel Tank | 28.3 GAL. |
Hydraulics
| Auxiliary Std Flow | 17.6 GPM |
| Auxiliary High Flow | 26.9 GPM |
Dimensions & Weight
| Width | 67 IN. |
| Operating Weight | 8927 lb |
Serviceability
Specifications subject to change without notice. Contact your local Carleton Equipment dealer to confirm details.
