R-Series
Bobcat
Configuration: Starting at $65,479

Rebates & Special Offers

View Full Offer

Get as low as 0% for 60 months* or $5,000 cash rebate* in lieu of financing.

Download Spec Sheet

Get detailed specifications, dimensions, and performance data for this T62 | Bobcat.

Download Spec Sheet →
General Info
Condition: Showroom
Manufacturer: Bobcat
Model: T62
Machine Type: Compact Track Loader
Coupler: Bob-Tach
Engine
Horsepower: 68.0
Performance
Rated Operating Capacity (ISO): 2,150 lb
Operating Weight: 8612 lb
Height to Bucket Hinge Pin: 114.5 IN.
Hydraulics
Aux. Standard Flow: 17.6 GPM
Aux. High Flow: 26.9 GPM
Dimensions
Width: 66.2 IN.
Fuel Tank: 28.3 GAL.

Description

Bobcat T62 Compact Track Loader

The Bobcat T62 R-Series compact track loader offers improved performance and durability on the jobsite. Featuring an inline engine and direct-drive system, excellent visibility and unmatched comfort, this radius-lift-path compact track loader – also referred to as a skid-steer with tracks – is engineered to get the big jobs done. Boasting an increased lifting capability, the 68-hp T62 delivers powerful digging and grading performance and generous reach at mid range heights.

Elevate your performance even higher thanks to powerful breakout forces and hydraulics, streamlined maintenance and fast cycle times. For enhanced comfort and productivity on long days, the T62 features a one-piece sealed and pressurized cab and advanced displays and precision controls. Our optional Clear-Side enclosure maximizes side visibility while our in-cab displays seamlessly integrate to the optional rear camera which can be set to on-demand, in reverse, or continuous rear views. A cast-steel Bob-Tach® attachment mounting system strengthens the loader’s connection point. Combine that with a redesigned Bobcat engine and lift arms with cast-steel construction and you have a compact machine tough enough to handle your biggest jobs, even in soft, sandy or muddy conditions.

  • Powerful and efficient Tier 4 non-DPF engine
  • Fast cycle times
  • Premium comfort
  • Reduced and simplified routine maintenance

Specs

Rated Operating Capacity 2,150 lb
Operating Weight 8,612 in
Ground Pressure - Rubber Track 5.64 psi
Auxiliary Standard Flow 17.6 gal/min
Auxiliary High Flow 26.9 gal/min
Emissions Tier Tier 4
Engine Fuel Diesel
Horsepower 68 hp
Turbocharged Engine Yes
Rated Operating Capacity 2,150 lb
Operating Capacity - 50% of Tip 3,071 lb
Tipping Load 6,143 lb
Operating Weight 8,612 lb
Travel Speed 7.2 mph
Travel Speed - 2 Speed Option 10.2 mph
Ground Pressure 5.64 psi
Auxiliary Standard Flow 17.6 GPM
Auxiliary High Flow 26.9 GPM
System Relief @ Quick Couplers 3,500 PSI
Length 134.9 in
Length without Attachment 107 in
Length with Standard Bucket 134.9 in
Width 67 in
Width with Bucket 68 in
Height 80.5 in
Height to Bucket Hinge Pin 114.5 in
Reach @ Maximum Height 23 in
Turning Radius 81.6 in
Length of Track on Ground 54.3 in
Track Width 12.6 in

Features

A radius lift path provides maximum reach at truck bed height. Arm movement forms an arc. More than 80% of that arc delivers better reach at truck bed height. A radius lift path excels in jobs at mid-range heights, like dumping, backfilling or unloading flatbed trucks.Bobcat Radius Lift Path
The large fan achieves more cooling at a slower rotation. This consumes less power and reduces noise in the cab and around the machine. A reversible fan option purges debris buildup from the rear screen, reducing the need for manual cleaning. An auto mode reverses airflow automatically, and operator-controlled purge mode gives
you the ability to reverse the
fan at any time.
DRIVE RESPONSE MODE

Drive response mode allows you to choose how the drive responds to joystick movement. Whether you like a more gradual response, quicker response or something in between, three different settings put you in control.

Bobcat Selectable Joystick Controls

SPEED MANAGEMENT

Simply “dial in” your required travel speed in small increments to match speed to your operation requirements and maximize attachment performance. Speed management gives you a full range of joystick motion with maximum driveline torque and full hydraulic power at slower machine speed.

STEERING DRIFT COMPENSATION

Steering drift compensation keeps you on a straight path by helping you make minor adjustments to the steering. It’s beneficial when you side-shift certain attachments, such as planers or trenchers, as this will tend to pull the machine to one side. You can also use it while driving on surfaces that cause the loader to gradually drift left or right, such as crowned roads. Make fine steering adjustments to either side and stay on target.

HORSEPOWER MANAGEMENT

Bobcat horsepower management automatically adjusts the loader drive system to maximize pushing and digging power while minimizing your chance of stalling. Unlike other anti-stall systems, Bobcat horsepower management lets the operator obtain maximum engine and drive torque to match the toughest digging conditions. If you prefer to work without it, simply disengage with the push of a button.

Use your iPhone® to control your machine remotely. Bobcat MaxControl remote operation is an iOS app that makes operating your machines easier and more convenient than ever before. It acts like an extra set of hands when help is limited. Two-person jobs can now be handled by one worker, and you can say goodbye to unnecessary trips in and out of the cab. Bobcat Maxcontrol Remote Control on Iphone
0%
for up to 60 months*
Financing Available
OR
$5,000USD*
cash rebate in lieu of financing
Customer Rebate

See participating dealers for details.

*Program disclosure: 0% A.P.R. financing for up to 60 months and $5,000 USD customer rebate offers are mutually exclusive — select one or the other. Financing subject to credit approval through an authorized Bobcat financing provider. Offer applied at time of purchase. Offers valid on qualifying new Bobcat compact track loader models through participating dealers only. See dealer for complete details, eligibility requirements, and program end dates. Offers subject to change without notice.

T62 Key Features

What Makes the T62 Different

68 HP Compact Track Loader Performance

The T62 delivers 68 hp with a 2,150 lb rated operating capacity and 6,143 lb tipping load for digging, grading, loading and material handling.

High Flow Hydraulics

Optional high-flow hydraulics increase output from 17.6 gpm to 26.9 gpm for running more demanding Bobcat attachments.

Two-Speed Travel Option

Optional two-speed travel helps operators move faster around the jobsite when the work calls for more travel between tasks.

Selectable Control Options

Joystick control is optional, giving owners a choice between familiar Bobcat operation and joystick control preferences.

Attachment Versatility

Standard auxiliary hydraulics, standard Bob-Tach and optional Power Bob-Tach help the T62 connect to a wide range of Bobcat loader attachments.

Non-Current Model Support

The T62 is a non-current model with parts, service and ownership support available, while Bobcat points new buyers to the current T64-2 compact track loader.

Compare the Family

Bobcat Compact Track Loaders

Bobcat T450 compact track loader
T550
 Bobcat T595 compact track loader Bobcat T62 compact track loader Bobcat T64-2 compact track loader Bobcat T66-2 compact track loader Bobcat T7X all-electric compact track loader Bobcat T650 compact track loader Bobcat T770 compact track loader Bobcat T76-2 compact track loader Bobcat T86-2 compact track loader
T450 T550 T595 T62Viewing T64-2 T66-2 T7X T650 T770 T76-2 T86-2
Frame / RoleCompact classicMid-size classicCurrent classicNon-current mid-frameMid-frameMid-frameAll-electricLarger classicLargest classicLarge-frameHigh-output large-frame
Horsepower55 hp68 hp70 hp68 hp68 hp74 hp100 hp74 hp92 hp74 hp115 hp
Rated Operating Capacity1,490 lbs1,995 lbs2,100 lbs2,150 lbs2,300 lbs2,400 lbs3,056 lbs2,500 lbs3,475 lbs2,900 lbs3,925 lbs
Tipping Load4,257 lbs5,700 lbs6,000 lbs6,143 lbs6,571 lbs6,857 lbs8,743 lbs7,143 lbs9,929 lbs8,285 lbs11,214 lbs
Operating Weight6,424 lbs7,557 lbs7,906 lbs8,612 lbs8,440 lbs8,560 lbs12,590 lbs8,980 lbs10,515 lbs9,592 lbs12,104 lbs
Travel Speed7 / 11 mph7.1 / 10.4 mph7.1 / 10.4 mph7.2 mph6.4 / 9.3 mph5.5 / 9.3 mph5.7 / 8.7 mph6 / 8.7 mph6.6 / 10.7 mph6.8 / 9.2 mph5.5 / 10.7 mph
Standard Aux Flow16.7 gpm17.1 gpm17.1 gpm17.6 gpm17.6 gpm17.6 gpmNo hydraulics23 gpm23 gpm23.3 gpm23 gpm
High / Super Flow—26.7 gpm26.7 gpm26.9 gpm26.9 gpm26.9 gpm—30.5 gpm36.6 gpm30.3 gpm36.6 / 42 gpm
Height to Hinge Pin109.5 in114.5 in119 in114.5 in120 in120 in128.4 in124 in132 in128.3 in144 in
Overall Width55 in67 in66.6 in67 in67.8 in67.8 in78 in72.9 in78 in73.5 in78 in

Specs are model-level published values. Confirm final configuration, options and current availability with your Carleton Equipment location.

T62

T62 Features & Benefits

Performance
68 HP Track Loader Power

The Bobcat T62 delivers 68 hp with a 2,150 lb rated operating capacity and 6,143 lb tipping load for everyday compact track loader work.

Track Loader Traction

A tracked undercarriage helps improve traction and flotation on soft, uneven or unfinished surfaces.

High-Flow Hydraulics

Standard auxiliary flow is 17.6 gpm, with optional high flow up to 26.9 gpm for higher-demand attachments.

Two-Speed Travel Option

Optional two-speed travel gives operators more flexibility when moving between tasks or traveling across larger jobsites.

Comfort & Control
Optional Joystick Control

Optional joystick control lets owners configure the T62 around the control style operators prefer.

Cab Comfort Options

Cab enclosure, air conditioning, cab heater, heater air conditioning, sound option and radio are available as options.

Standard Suspension Seat

A standard suspension seat helps reduce fatigue during long days of grading, loading and attachment work.

Deluxe Instrumentation Option

Optional Deluxe Instrumentation gives owners another way to tailor the operator station for daily use.

Serviceability
Engine Shutdown Protection

Standard engine shutdown protection helps protect the machine when operating conditions move outside normal limits.

Grease Track Tension

Standard grease track tensioning supports routine undercarriage maintenance and helps keep the loader ready for work.

Lift-Arm Support

Standard lift-arm support helps make routine service and inspection work more practical.

Bobcat Dealer Support

Carleton Equipment supports the T62 with Bobcat parts, service, attachments and local product knowledge across Michigan.

Versatility
Bob-Tach Attachment System

The standard Bob-Tach attachment system connects the T62 to a wide range of Bobcat loader attachments.

Power Bob-Tach Option

Optional Power Bob-Tach helps operators change many non-hydraulic attachments quickly from the cab.

Non-Current Model Path

The T62 is a non-current model; Bobcat points new buyers to the current T64-2 while supporting T62 owners with parts and service resources.

Bobcat T62 Compact Track Loader

Why Buyers Choose the T62

68 hp and 2,150 lb rated operating capacity for a capable compact track loader

6,143 lb tipping load with track traction for digging, grading, loading and material handling

Optional high-flow hydraulics up to 26.9 gpm for higher-demand attachments

Optional two-speed travel, ride control, hydraulic bucket positioning and rear hydraulics

Optional joystick control plus cab, heat, air conditioning, sound and radio options

Non-current model with Bobcat pointing new buyers to the current T64-2 compact track loader

Customers & Applications

Who Uses the T62 and What For

The T62 is a non-current compact track loader for owners and used-equipment buyers who want Bobcat track-loader capability, attachment flexibility and dealer support in a proven platform.

Construction & Site Prep

  • Grading, backfilling and site cleanup
  • Moving pallets, aggregate, soil and debris
  • Running buckets, forks, grapples and grading tools
  • Working where tracks help maintain traction

Landscape & Property Work

  • Preparing hardscape bases and spreading material
  • Using augers, soil tools, brush tools and snow attachments
  • Operating on softer or uneven ground
  • Handling seasonal grounds maintenance and snow removal

Used Equipment & Fleet Owners

  • Non-current model support through Bobcat parts and service resources
  • Familiar Bobcat attachment interface and compact-loader operation
  • Optional high flow expands attachment opportunities
  • Current new-machine step is the T64-2 compact track loader
Compact Track Loaders

Two Paths: Classic or Pro

Not sure which tier fits your application? Compare the full CTL lineup side by side.

Explore the Lineup

Full Specifications

Download Spec Sheet
General
ConditionShowroom
Machine TypeCompact Track Loader
Engine
Engine MakeBobcat
Horsepower68.0
Performance
ROC Solid Undercarriage2,150 lb
Loader Lift Height114.5 in
Bucket Hinge Pin Height114.5 IN.
Reach @ Max Height23 in
Tipping Load6,143 lbs
Travel Speed7.2 mph
Capacities
Fuel Tank28.3 GAL.
Hydraulics
System Relief @ Quick Couplers3,500 psi
Auxiliary Std Flow17.6 GPM
Auxiliary High Flow26.9 GPM
Dimensions & Weight
Ground Pressure5.6 psi
Height80.5 in
Length107 in
Width66.2 IN.
Operating Weight8612 lb
Turning Radius81.6 in
Length of track on ground54.3 in
Track Width12.6 in
Track Width - Optional15.7 in
Length with Standard Bucket134.9 in
Serviceability
Features
Joystick Control○ Optional
Air Conditioning○ Optional
Backup Alarm■ Standard
BICS System (Interlock)■ Standard
Cab Enclosure○ Optional
ROPS/FOPS Approved■ Standard
ROPS-Step— Not Applicable
Sound Option○ Optional
Cab Heater○ Optional
Heater Air Conditioning○ Optional
Operating Lights■ Standard
Work Lights■ Standard
Radio○ Optional
Rear Window■ Standard
Top Window■ Standard
Lift-Arm Support■ Standard
Grab Handles— Not Applicable
Seat Belt■ Standard 2-Point Lap Belt; Optional 3-Point Shoulder Belt on Two-Speed Models
Suspension Seat■ Standard
Two Speed Travel○ Optional
Deluxe Instrumentation○ Optional
Lockable Ignition— Not Applicable
Engine Shutdown■ Standard
Hydraulic Bucket Positioning○ Optional
High Flow Option○ Optional
Auxiliary Hydraulics■ Standard
3-Spool Valve— Not Applicable
Grease Track Tension■ Standard
Purifier Muffler Opt○ Optional
Spark Arrestor MufflerDOC
Bob-Tach Attachment System■ Standard
Power Bob-Tach○ Optional
Ride Control○ Optional
Rear Hydraulics○ Optional
Horn■ Standard

Specifications subject to change without notice. Contact your local Carleton Equipment dealer to confirm details.
