M5-091 Utility Tractors by Kubota

The M5 Series tractors are designed inside and out with features to provide the small hay/cattle producer and part-time farmer with productivity and comfort. These include an extra wide cab, three transmission options and many other deluxe features you would expect to find on more premium tractors.



PROVEN, POWERFUL AND RELIABLE KUBOTA DIESEL ENGINES

The M5 Series tractors are powered by the very popular V3800 series Kubota Diesel engine, which is a 3.8 liter, turbocharged, Tier 4 final engine. Packed with up to 105.6 HP, the M5 Series of tractors is ready for a multitude of heavy duty tasks.

Model

ROPS / CAB 2WD 2WD 4WD 4WD 4WD 4WD
ROPS / CAB HF ROPS HFC CAB HD ROPS HD12 ROPS HDC CAB HDC12 CAB


Engine

Type (Make: Kubota) 4 Cylinder In-Line, Common Rail System, Direct Injection, W/ Intercooler, DPF, DOC, SCR 4 Cylinder In-Line, Common Rail System, Direct Injection, W/ Intercooler, DPF, DOC, SCR 4 Cylinder In-Line, Common Rail System, Direct Injection, W/ Intercooler, DPF, DOC, SCR 4 Cylinder In-Line, Common Rail System, Direct Injection, W/ Intercooler, DPF, DOC, SCR 4 Cylinder In-Line, Common Rail System, Direct Injection, W/ Intercooler, DPF, DOC, SCR 4 Cylinder In-Line, Common Rail System, Direct Injection, W/ Intercooler, DPF, DOC, SCR
No. Of Cylinders / Aspiration 4 / Turbocharged 4 / Turbocharged 4 / Turbocharged 4 / Turbocharged 4 / Turbocharged 4 / Turbocharged
Rated Engine HP 92.5 HP 92.5 HP 92.5 HP 92.5 HP 92.5 HP 92.5 HP
Engine Net Power 85.5 HP 85.5 HP 85.5 HP 85.5 HP 85.5 HP 85.5 HP
PTO Power 76 HP 76 HP 76 HP 76 HP 76 HP 76 HP
Total Displacement 230 cu.in. 230 cu.in. 230 cu.in. 230 cu.in. 230 cu.in. 230 cu.in.
Rated Engine RPM 2400 RPM 2600 RPM 2400 RPM 2400 RPM 2600 RPM 2600 RPM
Fuel Tank Capacity 27.7 gal 27.7 gal 27.7 gal 27.7 gal 27.7 gal 27.7 gal
Alternator 60A 80A 60A 60A 80A 80A



Transmission

No. Of Speeds F8 / R8 F8 / R8 F8 / R8 F12 / R12 F8 / R8 F12 / R12
Main Gear Shift - Fully Synchronized 4 Speed 4 Speed 4 Speed 6 Speed 4 Speed 6 Speed
Dual Speed (Hi-Lo) N/A N/A N/A N/A N/A N/A
Shuttle Shift Electro Hydraulic-Shuttle Electro Hydraulic-Shuttle Electro Hydraulic-Shuttle Electro Hydraulic-Shuttle Electro Hydraulic-Shuttle Electro Hydraulic-Shuttle
Non-Clutch Shift N/A N/A N/A N/A N/A N/A
Main Clutch Type Multiple Wet Disc Multiple Wet Disc Multiple Wet Disc Multiple Wet Disc Multiple Wet Disc Multiple Wet Disc
Brake Type Hydraulic Wet Disc Hydraulic Wet Disc Hydraulic Wet Disc Hydraulic Wet Disc Hydraulic Wet Disc Hydraulic Wet Disc
Differential Lock (Front / Rear) Limited Slip Differential / Mechanical Limited Slip Differential / Mechanical Limited Slip Differential / Mechanical Limited Slip Differential / Mechanical Limited Slip Differential / Mechanical Limited Slip Differential / Mechanical
4WD Clutch Type Mechanical, on the go Mechanical, on the go Mechanical, on the go Mechanical, on the go Mechanical, on the go Mechanical, on the go



PTO

Type Live-Independent PTO, Electro-Hydraulic Clutch with Brake Live-Independent PTO, Electro-Hydraulic Clutch with Brake Live-Independent PTO, Electro-Hydraulic Clutch with Brake Live-Independent PTO, Electro-Hydraulic Clutch with Brake Live-Independent PTO, Electro-Hydraulic Clutch with Brake Live-Independent PTO, Electro-Hydraulic Clutch with Brake
Speed 540 540 540 540 / 540E 540 540 / 540E

Hydraulic

Pump Capacity (3-Point Hitch) 15.9 GPM 17 GPM 15.9 GPM 15.9 GPM 17 GPM 17 GPM
3-Point Hitch Telescopic Lower Link Ends, Telescopic Stabilizers Telescopic Lower Link Ends, Telescopic Stabilizers Telescopic Lower Link Ends, Telescopic Stabilizers Telescopic Lower Link Ends, Telescopic Stabilizers Telescopic Lower Link Ends, Telescopic Stabilizers Telescopic Lower Link Ends, Telescopic Stabilizers
Category II II II II II II
Control System Position, Draft (Top Link Sensing) & Mixed Control Position, Draft (Top Link Sensing) & Mixed Control Position, Draft (Top Link Sensing) & Mixed Control Position, Draft (Top Link Sensing) & Mixed Control Position, Draft (Top Link Sensing) & Mixed Control Position, Draft (Top Link Sensing) & Mixed Control
Lift Capacity at 24 in. Behind Lift Point (ISO) 4630 lbs 4630 lbs 4630 lbs 6063 lbs 4630 lbs 6063 lbs
Lift Capacity at 24 in. Behind Lift Point (ASAE) 5181 lbs 5181 lbs 5181 lbs 7275 lbs 5181 lbs 7275 lbs
Cylinder Type Two External Cylinders Two External Cylinders Two External Cylinders Two External Cylinders Two External Cylinders Two External Cylinders
No. Of Standard Remote Valves 1 (Max3) 1 (Max3) 1 (Max3) 1 (Max3) 1 (Max3) 1 (Max3)



Other Features



4WD System N/A N/A Bevel Gear Type with 55 Degree Turning Angle Bevel Gear Type with 55 Degree Turning Angle Bevel Gear Type with 55 Degree Turning Angle Bevel Gear Type with 55 Degree Turning Angle
Steering Hydrostatic Power Steering Hydrostatic Power Steering Hydrostatic Power Steering Hydrostatic Power Steering Hydrostatic Power Steering Hydrostatic Power Steering
Tilt Steering Standard Standard Standard Standard Standard Standard
Hood Type / Pedal Type Full Open, Slanted, Steel / Hanging Full Open, Slanted, Steel / Hanging Full Open, Slanted, Steel / Hanging Full Open, Slanted, Steel / Hanging Full Open, Slanted, Steel / Hanging Full Open, Slanted, Steel / Hanging
Deck Type (Rubber Mat) Full-Flat on ROPS/CAB Models Full-Flat on ROPS/CAB Models Full-Flat on ROPS/CAB Models Full-Flat on ROPS/CAB Models Full-Flat on ROPS/CAB Models Full-Flat on ROPS/CAB Models
Panel Type Electronic Electronic Electronic Electronic Electronic Electronic
Roof Window N/A STD N/A N/A STD STD
RPM Memory Standard Standard Standard Standard Standard Standard





Standard Tire Size

Front 7.5-18 F2 7.5-18 F2 11.2-24 R1 11.2-24 R1 11.2-24 R1 11.2-24 R1
Rear 18.4-28 R1 18.4-28 R1 18.4-28 R1 18.4-28 R1 18.4-28 R1 18.4-28 R1



Dimensions & Weight

Overall Length

156 in

156 in 155.9 in 155.9 in 155.9 in 155.9 in

Overall Height Top of ROPS / CAB

98.8 / - in

- / 100.2 in 98.8 / - in 98.8 / - in - / 100.2 in - / 100.2 in

Overall Width (Minimum)

77.2 in

77.2 in 78.3 in 78.3 in 78.3 in 78.3 in

Wheelbase

90 in

90 in 88.6 in 88.6 in 88.6 in 88.6 in

Crop Clearance (Front Axle)

20.5 in

20.5 in 18.7 in 18.7 in 18.7 in 18.7 in

Tread Width

Front
Rear

Inches

56.7-80.3
59.8-75.6

Inches

56.7-80.3
59.8-75.6

Inches

59.8-63.8
59.8-75.6

Inches

59.8-63.8
59.8-75.6

Inches

59.8-63.8
59.8-75.6

Inches

59.8-63.8
59.8-75.6

Turning Radius (w/o Brake)

12.1 ft

12.1 ft 13.8 ft 13.8 ft 13.8 ft 13.8 ft

Tractor Weight ROPS / CAB

5622 / - lbs

- / 6482 lbs 6041 / - lbs 6041 / - lbs - / 6900 lbs - / 6900 lbs
