L4701 Compact Tractor by Kubota

Meet your new favorite piece of equipment: Kubota's Standard L Series takes power and performance to new heights. With a valuable combination of horsepower and high-quality construction, this feature-packed compact tractor is perfect for small property owners – starting with how much you’ll look forward to using it every day.

#1 SELLING COMPACT TRACTOR BRAND*

Kubota is the top selling compact tractor brand in the USA – and has been for over a decade.*  Kubota quality is known in all circles, whether it be home owners, rental yards, or contractors. Kubota is proud to be #1 and also proud the L3301, L3901, L4701 and their corresponding front loaders and backhoes are assembled right here in the USA.

*Claim based on EDA/USS data for the period of 6/2007 through 6/2017 for new tractor sales in the Under 40 HP Utility Tractor, Utility Loader and Utility TLB Categories.

COMFORT IS KEY

The L01 Series Operator’s Station features:

  • Comfy Seat
  • Spacious Platform
  • Easy to Use Controls
  • Easy to Read Dash Panel

BUILT TO LAST

  • Steel Hood and Fenders
  • Kubota Diesel Engine
  • Cast Steel Transmission and Rear End Housing
  • Heavy Duty Front Axle

KUBOTA REPUTATION FOR QUALITY

Kubota is known for quality, reliability and longevity – you can’t fake a good reputation, it can only be awarded to you by your satisfied customers.

PERFORMANCE MATCHED IMPLEMENTS

Kubota Front End Loaders and Backhoes are performance matched, meaning they are designed for the maximum capacities that the base tractor can handle. With Kubota performance matched implements, you know you are getting the most out of your piece of equipment.

Model

L4701
Gear-Drive Transmission Gear-Drive Transmission HST
2WD 4WD 4WD



Engine

Type Direct Injection, Vertical, Water-Cooled 4 Cycle Diesel Direct Injection, Vertical, Water-Cooled 4 Cycle Diesel Direct Injection, Vertical, Water-Cooled 4 Cycle Diesel
Engine Gross Power 47.3 HP 47.3 HP 47.3 HP
Engine Net Power 44.8 HP 44.8 HP 44.8 HP
PTO Power 39.3 HP 39.3 HP 37.8 HP
Number of Cylinders 4 4 4
Bore & Stroke 3.4 x 4 in 3.4 x 4 in 3.4 x 4 in
Total Displacement 148.5 cu.in. 148.5 cu.in. 148.5 cu.in.
Rated Speed 2600 rpm 2600 rpm 2600 rpm
Battery 12V: 120 min, CCA: 600 A 12V: 120 min, CCA: 600 A 12V: 120 min, CCA: 600 A
Alternator 12V, 40A 12V, 40A 12V, 40A
Fuel Tank Capacity 13.5 Gal 13.5 Gal 13.5 Gal



PTO

Rear PTO Type Live-Independent Hydraulic PTO with PTO Brake, Wet Clutch Live-Independent Hydraulic PTO with PTO Brake, Wet Clutch Live-Independent Hydraulic PTO with PTO Brake, Wet Clutch
PTO/Engine Speed 540/2475 540/2475 540/2640



Hydraulic

Lift Control Type Position Control Position Control Position Control
Pump Capacity
Main
PS
Gallons
8.4
5.1
Gallons
8.4
5.1
Gallons
8.4
5.1
3-Point Hitch Category I Category I Category I
Lift Capacity
Lift Points
24 in. Behind Lift Points
Pounds
2870
2320
Pounds
2870
2320
Pounds
2870
2320
System Pressure 180 kgf/cm² 180 kgf/cm² 180 kgf/cm²



Travelling System

Transmission Constant Mesh with Synchronized Shuttle, 8 Forward and 8 Reverse Constant Mesh with Synchronized Shuttle, 8 Forward and 8 Reverse Hydrostatic Transmission, 3 Range Speed
Steering Hydrostatic Power Steering Hydrostatic Power Steering Hydrostatic Power Steering
Brake Mechanical, Wet Disc Type Mechanical, Wet Disc Type Mechanical, Wet Disc Type
Clutch Dry Type Single Stage Dry Type Single Stage No Clutch



Tire Size

AG Standard (Front / Rear)

7.5L-15 / 14.9-24 8.3-16 / 14.9-24 8.3-16 / 14.9-24
TURF Option (Front / Rear) 27 x 8.50-15 / 44 x 18-20 27 x 10.5 / 44 x 18-20, 27 x 8.5-15 44 x18-20, 305R343LSW / 44 x 18-20 27 x 10.5 / 44 x 18-20, 27 x 8.5-15 44 x18-20, 305R343LSW / 44 x 18-20
Industrial Option (Front / Rear) N/A 10-16.5 / 17.5L-24 10-16.5 / 17.5L-24



Travelling Speed with Standard AG Tires

Forward 1.4-14.9 mph 1.4-14.9 mph 0-15.8 mph
Reverse 1.3-14.3 mph 1.3-14.3 mph 0-14.2 mph



Dimensions

Overall Length (w/o 3P 122.8 in 119.5 in 119.5 in
Overall Width (Min. Tread) 62.4 in 62.4 in 62.4 in
Overall Height (w/ Foldable ROPS) 91.7 in 91.7 in 91.7 in
Wheelbase 72.8 in 72.6 in 72.6 in
Min. Ground Clearance 15.2 in 15.2 in 15.2 in
Tread
Front Tire
Rear Tire
Inches

50.4

54.3

58.3

62.2

46.5 / 47.2 / 51.2 / 57.1 / 60.8
Inches
45.5
46.5 / 47.2 / 51.2 / 57.1 / 60.8
Inches
45.5
46.5 / 47.2 / 51.2 / 57.1 / 60.8
Min. Turning Radius (W/ Brake, 4WD Disengaged) 8.9 ft 8.5 ft 8.5 ft
Weight (With ROPS) 3219 lbs 3296 lbs 3307 lbs
