The Fecon FTX150-2 Mulching Tractor is ideal for all forestry mulching applications. From large scale right of way maintenance to vegetation management and lot clearing jobs, the FTX150-2’s 150 HP class power and versatility allow any job to be completed with confidence and ease.
The FTX150-2 is the only dedicated forestry machine in its class with Loader Arms
The Loader Arms give the operator an increased range of motion & finite control over the mulching head
Constant monitoring of the hydraulic circuits allows for engine horsepower to be routed to where it is needed most
The system allows for the FTX150-2 to mulch uphill while maintaining control over both the loader arms and track system
Fecon Power Management optimizes both the recovery and staying power of the mulching head
The D3 undercarriage in the FTX150-2 is designed for the toughest mulching applications, resulting in longer track life and less downtime
Ground clearance on the FTX150-2 is 21”
Optional Severe Duty Forestry Skids on the FTX150-2 provide added longevity to the tracks in severe applications
Dimensions
FTX150-2 Specs
Overall Height
103" (8' 7")
Overall Width
72.5" (6' 1/2")
Overall Width with Bullhog
87" (7' 3")
Overall Length
169" (14' 1")
Overall Length with Bullhog
214" (17' 10")
Weight
17,250 lbs
Weight with Bullhog
20,900 lbs
Ground Pressure with Bullhog
4.8 psi
Travel Speed
4 mph
Engine
FTX150-2 Specs
Make
Cummins F3.8
Displacement
3.8L
Cylinders
4
After Treatment
Tier 4 Final, Stage V
Max Horsepower
155 HP
Max Torque
457 ft*lb @ 1500 RPM
Fuel Consumption
4-5 gph
Fuel Tank Capacity
45 gal
DEF Consumption
0.3-0.4 gph
DEF Tank Capacity
5 gal
Electrical System
12V
Battery
Dual 12V
Slope Rating
40° All Directions
Undercarriage
FTX150-2 Specs
Class
D3
Manufacturer
ITR
Track Width
20'
Standard Grouser
Single
Rollers
2 Top / 7 Bottom
Ground Clearance
21"
Performance
FTX150-2 Specs
Mulcher Circuit
60 GPM @ 5000 psi
Auxiliary Circuit
28 GPM @ 3000 psi
Hydraulic Tank Capacity
55 gal
Attachments
FTX150-2 Specs
Standard Attachment
BH85SD Bullhog
Mounting Style
Pin On
Lift Style
Loader Arms
Max Reach with Bullhog
137" (11' 5") to Bottom of Rotor
Max Below Grade with Bullhog
32"
Standard Features
Pressurized Cab
Suspension Seat
Bluetooth Radio
USB Charging Ports
Cell Phone Mount
Rearview Camera
2 Cup Holders
7" Touch Screen Monitor
Job Timers
Fecon Power Management
Dual Engine Air Cleaner with Pre-cleaner
Reversing Hydraulic Cooling Fan- Hydraulic Driven
In Cab Flow Adjustment
4 Points of Egress
Roof Skylight
Adjustable Joystick Pods
Clipped Corner Grousers
Trapezoidal Track Mud Reliefs
3 Single, 4 Double Flange Rollers
SALT Track Chain
Forward & Rear LED Lights
Cab Debris Screen
Connectivity with Phone App
Lage Service Doors on Engine Compartment - Lockable
