General Info
Condition:	Rental
Manufacturer:	Bobcat
Model:	T870
Machine Type:	Skid/Track Loader
Coupler:	Bob-Tach

Engine
Horsepower:	100.0
Emissions:	Tier 4

Performance
Rated Operating Capacity (ISO):	3,650 LB
Tipping Load:	10,430 lb.
Operating Weight:	12925 lb
Travel Speed:	5.5-9.3 mph

Hydraulics
Aux. Standard Flow:	23 GPM
Aux. High Flow:	36.6 GPM

Dimensions
Height:	84.8 in.
Length:	154 in.
Width:	82.8 in.
Turning Radius:	99 in.
Fuel Tank:	32.6 gal.

Bobcat T870 Series - Rental

Name: Bobcat T870 Series - Rental
Brand: Bobcat
SKU: FE81784E
Price: 514.00 USD
Availability: InStock

Experience exceptional power and lift capabilities with the Bobcat T870 Series, the largest compact track loader in the Bobcat lineup. Equipped with a robust 100-hp diesel engine and an impressive industry-leading 12-ft. lift height, this machine is ideal for demanding construction, landscaping, and agricultural tasks. Its rated operating capacity of 3,650 lb and a tipping load of 10,430 lb help you move heavy loads with ease, while the advanced hydraulic system provides smooth operation. The T870 is designed for operator comfort and reliability, helping maximize productivity on any jobsite.

Description

The vertical lift path Bobcat® M2-Series T870 is a powerful workhorse. Whether you’re lifting, digging, or hauling, this machine’s performance and endurance make it perfect for a wide range of projects.

Specs

Engine

Emissions Tier (EPA)	Tier 4
Engine Cooling	Liquid
Engine Fuel	Diesel
Horsepower	100
Turbocharged Engine	Yes

Performance

Rated Operating Capacity (ISO)	3,650 lb
Operating Capacity (50% of Tip)	5,200 lb
Tipping Load	10,430 lb
Operating Weight	12,925 lb
Travel Speed	5.5 mph
Travel Speed (2 - Speed Option)	9.3 mph
Ground Pressure (Rubber)	4.8 psi

Capacities

Fuel Tank

32.6 gal

Hydraulic System

System Relief @ Quick Couplers	3,500 psi
Auxiliary Std Flow	23 gal/min
Auxiliary High Flow	36.6 gal/min

Dimension

Length	154 in
Length Without Attachment	119.3 in
Length With Standard Bucket	154 in
Width	82.8 in
Width (With Bucket)	84.8 in
Height	84.8 in
Height With Operator Cab	84.8 in
Height to Bucket Hinge Pin	145.4 in
Reach @ Maximum Height	37.5 in
Turning Radius	99 in
Length of Track on Ground	70.2 in
Track Width	17.7 in

Compare the Family

Bobcat Compact Track Loaders

		T550		T62
	T450	T550	T595	T62	T64-2	T66-2	T7X	T650	T770	T76-2	T86-2
Frame / Role	Compact classic	Mid-size classic	Current classic	Non-current mid-frame	Mid-frame	Mid-frame	All-electric	Larger classic	Largest classic	Large-frame	High-output large-frame
Horsepower	55 hp	68 hp	70 hp	68 hp	68 hp	74 hp	100 hp	74 hp	92 hp	74 hp	115 hp
Rated Operating Capacity	1,490 lbs	1,995 lbs	2,100 lbs	2,150 lbs	2,300 lbs	2,400 lbs	3,056 lbs	2,500 lbs	3,475 lbs	2,900 lbs	3,925 lbs
Tipping Load	4,257 lbs	5,700 lbs	6,000 lbs	6,143 lbs	6,571 lbs	6,857 lbs	8,743 lbs	7,143 lbs	9,929 lbs	8,285 lbs	11,214 lbs
Operating Weight	6,424 lbs	7,557 lbs	7,906 lbs	8,612 lbs	8,440 lbs	8,560 lbs	12,590 lbs	8,980 lbs	10,515 lbs	9,592 lbs	12,104 lbs
Travel Speed	7 / 11 mph	7.1 / 10.4 mph	7.1 / 10.4 mph	7.2 mph	6.4 / 9.3 mph	5.5 / 9.3 mph	5.7 / 8.7 mph	6 / 8.7 mph	6.6 / 10.7 mph	6.8 / 9.2 mph	5.5 / 10.7 mph
Standard Aux Flow	16.7 gpm	17.1 gpm	17.1 gpm	17.6 gpm	17.6 gpm	17.6 gpm	No hydraulics	23 gpm	23 gpm	23.3 gpm	23 gpm
High / Super Flow	—	26.7 gpm	26.7 gpm	26.9 gpm	26.9 gpm	26.9 gpm	—	30.5 gpm	36.6 gpm	30.3 gpm	36.6 / 42 gpm
Height to Hinge Pin	109.5 in	114.5 in	119 in	114.5 in	120 in	120 in	128.4 in	124 in	132 in	128.3 in	144 in
Overall Width	55 in	67 in	66.6 in	67 in	67.8 in	67.8 in	78 in	72.9 in	78 in	73.5 in	78 in
