Bobcat
Based on 7 day Rental - As low as*- Daily - $185
Online Estimate:
$185.00 /Daily*
Stock:
In stock
General Info
Condition: Rental
Manufacturer: Bobcat
Model: T595
Machine Type: Compact Track Loader
Coupler: Bob-Tach
Engine
Horsepower: 70.0
Emissions: Tier 4
Performance
Rated Operating Capacity (ISO): 2,200 lb
Tipping Load: 6,517 lb
Operating Weight: 8022 lb
Travel Speed: 7.1 mph
Height to Bucket Hinge Pin: 119 in.
Hydraulics
Aux. Standard Flow: 17.1 GPM
Dimensions
Height: 77.8 in.
Length: 133 in.
Width: 67 in.
Turning Radius: 80 in.
Fuel Tank: 36.5 gal.

Description

Bobcat T595 Series - Rental

The Bobcat T595 is designed to help you work efficiently across demanding jobsites. Its 70-horsepower diesel engine provides reliable power to handle tough digging, leveling, and loading tasks. The vertical lift arm path raises heavy materials smoothly, making it simpler to load trucks or tackle elevated work. With a fuel tank capacity of 36.5 gallons, you can keep operating this compact track loader for extended periods before refueling. The T595 offers a spacious operator cab and enhanced hydraulics to deliver quick cycle times, improve productivity, and make maintenance straightforward. Explore its full specifications below to see why the T595 is a strong choice for your project.

Description

Take productivity to new heights with powerful breakout forces and hydraulics, streamlined maintenance and fast cycle times.

Specs

Engine

Emissions Tier (EPA) Tier 4
Engine Cooling Liquid
Engine Fuel Diesel
Horsepower 70
Turbocharged Engine

Optional

Performance

Rated Operating Capacity (ISO) 2,200 lb
Operating Capacity (50% of Tip) 3,142 lb
Tipping Load 6,517 lb
Operating Weight 8,022 lb
Travel Speed 7.1 mph
Travel Speed (2 - Speed Option) 10.1 mph
Ground Pressure (Rubber) 5.1 psi

Capacities

Fuel Tank 36.5 gal

Hydraulic System

System Relief @ Quick Couplers 3,550 psi
Auxiliary Std Flow 17.1 gal/min
Auxiliary High Flow n/a

Dimension

Length 133 in
Length Without Attachment 104.5 in
Length With Standard Bucket 133 in
Width 67 in
Width (With Bucket)  68 in
Height 77.8 in
Height With Operator Cab 77.8 in
Height to Bucket Hinge Pin 119 in
Reach @ Maximum Height 34.9 in
Turning Radius 80 in
Length of Track on Ground

54.1 in
Track Width

12.6 in
T595 Key Features

What Makes the T595 Different

Vertical Lift Path

Vertical lift path raises loads straight up for more reach at full height, giving you the confidence to place materials accurately and handle heavier loads on demanding jobs.

High Flow Hydraulics

High-flow option delivers more hydraulic output for expanded attachment versatility, including trenchers, stump grinders, drum mulchers and more.

Two-Speed Travel

Spend less time traveling across the jobsite or between jobs with this option. Move faster – and get the job done sooner.

Power Bob-Tach

This option easily and quickly changes non-hydraulic attachments in seconds right from your seat with the push of a button. No dismounting. No wasted motion.

Standard or Selectable Joystick Control

Selectable joystick control (SJC) comes standard, with optional hand and foot controls available to suit your preferences and work needs.

Non-DPF Engine

Engines meet emissions requirements without a diesel particulate filter (DPF), eliminating the need for time-consuming regeneration.

Deluxe Display With Rearview Camera Integration

With a standard Deluxe Display and rearview camera integration, the T595 gives operators a more informed, confident view of the job. It’s a straightforward feature that supports jobsite awareness and everyday ease of operation.

Compare the Family

Bobcat Compact Track Loaders

Bobcat T450 compact track loader
T550
 Bobcat T595 compact track loader
T62
 Bobcat T64-2 compact track loader Bobcat T66-2 compact track loader Bobcat T7X all-electric compact track loader Bobcat T650 compact track loader Bobcat T770 compact track loader Bobcat T76-2 compact track loader Bobcat T86-2 compact track loader
T450 T550 T595Viewing T62 T64-2 T66-2 T7X T650 T770 T76-2 T86-2
Frame / RoleCompact classicMid-size classicCurrent classicNon-current mid-frameMid-frameMid-frameAll-electricLarger classicLargest classicLarge-frameHigh-output large-frame
Horsepower55 hp68 hp70 hp68 hp68 hp74 hp100 hp74 hp92 hp74 hp115 hp
Rated Operating Capacity1,490 lbs1,995 lbs2,100 lbs2,150 lbs2,300 lbs2,400 lbs3,056 lbs2,500 lbs3,475 lbs2,900 lbs3,925 lbs
Tipping Load4,257 lbs5,700 lbs6,000 lbs6,143 lbs6,571 lbs6,857 lbs8,743 lbs7,143 lbs9,929 lbs8,285 lbs11,214 lbs
Operating Weight6,424 lbs7,557 lbs7,906 lbs8,612 lbs8,440 lbs8,560 lbs12,590 lbs8,980 lbs10,515 lbs9,592 lbs12,104 lbs
Travel Speed7 / 11 mph7.1 / 10.4 mph7.1 / 10.4 mph7.2 mph6.4 / 9.3 mph5.5 / 9.3 mph5.7 / 8.7 mph6 / 8.7 mph6.6 / 10.7 mph6.8 / 9.2 mph5.5 / 10.7 mph
Standard Aux Flow16.7 gpm17.1 gpm17.1 gpm17.6 gpm17.6 gpm17.6 gpmNo hydraulics23 gpm23 gpm23.3 gpm23 gpm
High / Super Flow—26.7 gpm26.7 gpm26.9 gpm26.9 gpm26.9 gpm—30.5 gpm36.6 gpm30.3 gpm36.6 / 42 gpm
Height to Hinge Pin109.5 in114.5 in119 in114.5 in120 in120 in128.4 in124 in132 in128.3 in144 in
Overall Width55 in67 in66.6 in67 in67.8 in67.8 in78 in72.9 in78 in73.5 in78 in

Specs are model-level published values. Confirm final configuration, options and current availability with your Carleton Equipment location.

T595

T595 Features & Benefits

Performance
70 HP Everyday Workhorse

The Bobcat T595 delivers 70 hp with a 2,100 lb rated operating capacity and 6,000 lb tipping load for digging, grading, loading and material handling.

Vertical Lift Path

The vertical lift path gives operators better reach at full height for loading trucks, placing pallets and handling material where lift height matters.

High-Flow Hydraulics

Standard auxiliary flow is 17.1 gpm, with optional high flow up to 26.7 gpm for running higher-demand Bobcat attachments.

Two-Speed Travel Option

Two-speed travel gives the T595 a 10.4 mph high range, helping crews spend less time moving around the jobsite.

Comfort & Control
Standard Selectable Joystick Control

Selectable joystick control comes standard, with optional hand and foot controls available for operators who prefer a classic control pattern.

Cab Comfort Options

Available cab enclosure, heat and air conditioning options let owners configure the T595 for year-round productivity.

Deluxe Display With Rearview Camera Integration

The standard Deluxe Display and rearview camera integration support better jobsite awareness and easier day-to-day operation.

Suspension Seat

A standard suspension seat helps reduce fatigue during long days of grading, loading, carrying and attachment work.

Serviceability
Non-DPF Engine

The non-DPF emissions system avoids diesel particulate filter regeneration, helping operators stay focused on the job.

Grease Track Tension

Standard grease track tensioning supports routine undercarriage maintenance and helps keep the loader ready for work.

Engine Shutdown Protection

Standard engine shutdown protection helps protect the machine when operating conditions move outside safe limits.

Bobcat Dealer Support

Carleton Equipment supports the T595 with Bobcat parts, service, attachments and local product knowledge across Michigan.

Versatility
Bob-Tach Attachment System

The standard Bob-Tach attachment system connects the T595 to a wide range of Bobcat loader attachments.

Power Bob-Tach Option

Optional Power Bob-Tach helps operators change many non-hydraulic attachments quickly from the cab.

Attachment-Ready Classic CTL

Optional high flow, vertical lift and familiar Bobcat controls make the T595 a strong match for site prep, landscape, construction and rental work.

Bobcat T595 Compact Track Loader

Why Buyers Choose the T595

70 hp and 2,100 lb rated operating capacity for a capable classic CTL workhorse

Vertical lift path with 119 in hinge-pin height and 34.5 in reach for loading and placing material

Optional high-flow hydraulics up to 26.7 gpm for higher-demand attachments

Two-speed travel reaches up to 10.4 mph for faster jobsite movement

Standard selectable joystick control with optional hand and foot controls

Non-DPF engine, Deluxe Display and rearview camera integration support daily uptime and visibility

Customers & Applications

Who Uses the T595 and What For

The T595 is a current classic compact track loader for crews that want vertical-lift loading performance, useful hydraulic flow and familiar Bobcat operation in a proven package.

Contractors & Site Prep

  • Loading trucks, placing pallets and moving site materials
  • Backfilling, grading and cleanup on residential or commercial jobs
  • Running buckets, forks, breakers, trenchers and grading tools
  • Working where track traction helps keep production moving

Landscaping & Grounds

  • Preparing hardscape bases and spreading aggregate
  • Using augers, grapples, soil tools, brush tools and snow attachments
  • Reducing rutting on softer finished or semi-finished surfaces
  • Handling seasonal grounds maintenance and snow removal

Rental & Fleet Owners

  • Current classic CTL platform with broad customer appeal
  • Optional high flow expands attachment rental opportunities
  • Standard SJC gives operators a modern control experience
  • Supported by Carleton Equipment parts, service and attachment expertise
Compact Track Loaders

Two Paths: Classic or Pro

Not sure which tier fits your application? Compare the full CTL lineup side by side.

Explore the Lineup

Full Specifications

General
ConditionRental
Machine TypeCompact Track Loader
Engine
Engine MakeBobcat
Alternator90A
Battery Size650A
Engine-High Idle2,600 RPM
Engine-Low Idle1,050 RPM
Air Cleaner ElementsReplacable dry paper cartridge with seperate safety element
Horsepower70.0
EmissionsTier 4
Performance
ROC Solid Undercarriage2,200 lb
Rated Operating Capacity 200 lb. Counterweight2,200 lbs (200 lb counterweight)
Loader Lift Height119 in
Bucket Hinge Pin Height119 in.
Reach @ Max Height34.5 in
Tipping Load6,517 lb
Travel Speed7.1 mph
Capacities
Fuel Tank36.5 gal.
Hydraulics
System Relief @ Quick Couplers3,450 psi
Auxiliary Std Flow17.1 GPM
Auxiliary High Flow26.7 gpm
Dimensions & Weight
Ground Pressure5.1 psi
Height77.8 in.
Length133 in.
Width67 in.
Operating Weight8022 lb
Turning Radius80 in.
Length of track on ground54.1 in
Track Width12.6 in
Track Width - Optional15.8 in
Length with Standard Bucket132.5 in
Serviceability
Features
Joystick Control■ Standard
Air Conditioning○ Optional
Backup Alarm■ Standard
BICS System (Interlock)■ Standard
Cab Enclosure○ Optional
ROPS/FOPS Approved■ Standard
ROPS-Step— Not Applicable
Sound Option○ Optional
Cab Heater○ Optional
Heater Air Conditioning○ Optional
Operating Lights■ Standard
Work Lights■ Standard
Rear Window■ Standard
Top Window■ Standard
Grab Handles— Not Applicable
Seat Belt■ Standard
Suspension Seat■ Standard
Two Speed Travel— Not Applicable
Deluxe Instrumentation○ Optional
Lockable Ignition— Not Applicable
Engine Shutdown■ Standard
Hydraulic Bucket Positioning○ Optional
High Flow Option○ Optional
Auxiliary Hydraulics■ Standard
3-Spool Valve— Not Applicable
Grease Track Tension■ Standard
Spark Arrestor Muffler■ Standard
Bob-Tach Attachment System■ Standard
Power Bob-Tach○ Optional
ACS (Switchable Controls)— Not Applicable
Ride Control○ Optional
Horn■ Standard

Specifications subject to change without notice. Contact your local Carleton Equipment dealer to confirm details.
