Bobcat S66 Series - Rental

Bobcat
Based on 7 day Rental - As low as*- Daily - $157
Online Estimate:
$157.00 /Daily*
General Info
Condition: Rental
Manufacturer: Bobcat
Model: S66
Machine Type: Skid Steer Loader
Coupler: Bob-Tach
Engine
Horsepower: 74.0
Emissions: Tier 4
Performance
Rated Operating Capacity (ISO): 2,400 lb
Tipping Load: 4,800 lb
Operating Weight: 7154 lb
Travel Speed: 7.4-11 mph
Height to Bucket Hinge Pin: 120 in.
Hydraulics
Aux. Standard Flow: 17.6 GPM
Aux. High Flow: 26.9 GPM
Dimensions
Height: 80.5 in.
Length: 135 in.
Width: 67 in.
Wheelbase: 44.6 in.
Turning Radius: 80.1 in.
Fuel Tank: 28.3 gal.

Description

Bobcat S66 Series - Rental

Experience the power and efficiency of the Bobcat® S66 skid-steer loader, built to help you tackle a wide range of demanding tasks with ease. Its 74-horsepower diesel engine delivers strong performance, while the vertical lift arm path gives you excellent reach at maximum height—ideal for loading and unloading materials. With a robust rated operating capacity of 2,400 lb, the S66 helps you move heavy loads and boost productivity on every job. Plus, the thoughtfully designed cab keeps operators comfortable, and Bob-Tach™ coupler compatibility allows quick attachment changes, improving overall efficiency on your worksite.

Rental Rates

Daily Weekly Monthly
$350 $1,100 Call for Pricing Plans
Description

The Bobcat® S66 skid-steer loader is engineered to take on your toughest jobs. From landscaping to construction projects, this skid-steer offers versatility and efficiency. Its compact footprint makes maneuvering simple, while strong hydraulics ensure responsive lifting and digging.

Specs

Engine

Emissions Tier (EPA) Tier 4
Engine Cooling Liquid
Engine Fuel Diesel
Horsepower 74
Turbocharged Engine Yes

Performance

Rated Operating Capacity (ISO) 2,400 lb
Tipping Load 4,800 lb
Operating Weight 7,154 lb
Travel Speed 7.4 mph
Travel Speed (2 - Speed Option) 11 mph

Capacities

Fuel Tank 28.3 gal

Hydraulic System

Auxiliary Std Flow 17.6 gal/min
Auxiliary High Flow 26.9 gal/min

Dimension

Length 135 in
Length Without Attachment 107 in
Length With Standard Bucket 135 in
Width 67 in
Width (With Bucket) 68 in
Height 80.5 in
Height With Operator Cab 80.5 in
Height to Bucket Hinge Pin 120 in
Reach @ Maximum Height 34.2 in
Turning Radius 80.1 in
Wheelbase 44.6 in
S66 Key Features

What Makes the S66 Different

Inline Engine and Direct-Drive System

The R-Series S66 pairs an inline Bobcat engine with a durable direct-drive system to make challenging work days easier. The non-DPF Tier 4 design avoids diesel particulate filter regeneration downtime and simplifies routine maintenance.

Standard Two-Speed Travel

Two-speed travel comes standard on the S66, boosting top speed to 11 mph. Reduce travel time across jobsites, limit trailer loading and unloading, and shorten long-haul tasks.

Super Float Tires

Bobcat Super Float tires come standard for precision turning, skidding and maneuverability with minimal soil disturbance.

Cast-Steel Lift Arms

Cast-steel lift arm sections and optimized lift-arm linkage give the vertical-lift-path S66 stronger lifting capability, with a slimmer arm profile that also enhances visibility.

Improved Cooling System

The R-Series cooling system is completely redesigned for optimal operation and maximum uptime when operators run longer and take on bigger, more difficult jobs.

Clear-Side Cab and In-Cab Display

A one-piece sealed and pressurized cab, optional clear-side enclosure with mesh-free polycarbonate windows, and an in-cab display with machine information and performance data help maximize productivity.

Compare the Family

Bobcat Skid-Steer Loaders

Bobcat S70 skid-steer loader Bobcat S450 skid-steer loader
S510
 Bobcat S590 skid-steer loader
S62
 Bobcat S64-2 skid-steer loader Bobcat S66-2 skid-steer loader Bobcat S650 skid-steer loader Bobcat S76-2 skid-steer loader Bobcat S770 skid-steer loader Bobcat S86-2 skid-steer loader
S70 S450 S510 S590 S62 S64-2 S66Viewing S650 S76-2 S770 S86-2
Frame / RoleUltra-compact classicCompact classicMid-size classic, radius liftMid-size classicMid-frame radius liftMid-frame ProMid-frame ProLarge classicLarge-frame ProLargest classicHigh-output large-frame
Horsepower23.5 hp49 hp55 hp68 hp68 hp68 hp74 hp74 hp74 hp92 hp115 hp
Rated Operating Capacity760 lbs1,370 lbs1,876 lbs2,000 lbs2,100 lbs2,300 lbs2,400 lbs2,690 lbs2,900 lbs3,350 lbs3,500 lbs
Tipping Load1,520 lbs2,740 lbs3,560 lbs4,000 lbs4,200 lbs4,600 lbs4,800 lbs5,380 lbs5,800 lbs6,700 lbs7,000 lbs
Operating Weight2,892 lbs5,370 lbs6,208 lbs6,649 lbs6,884 lbs6,855 lbs7,154 lbs7,901 lbs8,014 lbs9,154 lbs10,098 lbs
Travel Speed6.3 mph7.6 / 9.2 mph7.6 mph7.3 / 11.7 mph7.4 / 11 mph7.4 / 11 mph7.4 / 11 mph7.1 / 12.3 mph6.8 / 11.8 mph7.1 / 12.3 mph7.1 / 12.3 mph
Standard Aux Flow8.9 gpm16.7 gpm17.1 gpm17.1 gpm17.6 gpm17.6 gpm17.6 gpm23 gpm23.3 gpm23 gpm23 gpm
High / Super Flow———26.7 gpm26.9 gpm26.9 gpm26.9 gpm30.5 gpm30.3 gpm36.6 gpm36.6 / 42 gpm
Height to Hinge Pin94.5 in109.5 in114.5 in119 in114.5 in120 in120 in124 in128.3 in132 in144 in
Overall Width35.5 in58.6 in68 in (with bucket)64.7 in68 in (with bucket)64.6 in67 in72.1 in72 in72.1 in72 in
VersatilityUltra-compact accessCompact jobsite fitRadius-lift digging and pushingVertical-lift material handlingRadius-lift reach, high-flow optionPro packages, high-flow optionPro packages, stronger attachment flowLarge-frame lift and attachmentsLarge-frame Pro packagesLarge classic lift capacityHigh-output Pro hydraulics
ServiceabilitySimple daily accessNon-DPF engineFull-access serviceabilityService-friendly loader layoutNon-DPF engine, simplified maintenanceEngine shutdown, lift-arm supportEngine shutdown, lift-arm supportDealer-supported classic platformPro platform service accessDealer-supported classic platformPro platform service access

Specs are model-level published values. Confirm final configuration, options and current availability with your Carleton Equipment location.

View All Skid-Steer Loaders Learn About Sizes, Types & Specs Find a Local Dealer
S66

S66 Features & Benefits

Performance 3
74 HP R-Series Power

The S66 delivers 74 hp, a 2,400 lb rated operating capacity and a 4,800 lb tipping load, with fast cycle times for heavier skid-steer loader work in tight areas.

Powerful Hydraulics

Standard 17.6 gpm auxiliary hydraulics and optional 26.9 gpm high flow at 3,500 psi help match the machine to demanding Bobcat attachments.

Standard Two-Speed Travel

Standard two-speed travel raises top speed from 7.4 mph to 11 mph, helping operators move faster across yards, lots and larger jobsites.

Comfort & Control 3
Selectable Joystick Controls

Optional Selectable Joystick Controls (SJC) include horsepower management and Bobcat-exclusive customization, and SJC-equipped loaders can be run by a portable remote-control system.

Operator-Focused Cab Options

A sealed and pressurized cab, clear-side enclosure, automatic heat and air conditioning, sound dampening and an optional heated cloth air-ride seat help configure the S66 for longer workdays.

In-Cab Display Options

The standard display provides full-featured machine monitoring, and the optional touch display adds detailed machine information and device connectivity on a waterproof, scratch-hardened screen.

Versatility 3
Bob-Tach Attachment System

The standard Bob-Tach mounting system helps the S66 switch quickly between buckets, forks, grapples, snow tools and other approved attachments.

Power Bob-Tach Option

Upgrade to Power Bob-Tach, available on select models, to swap non-hydraulic attachments without leaving the seat.

Application-Matched Options

High flow, automatic ride control, dual-direction bucket positioning, the attachment control kit and Features on Demand help tailor the loader to the work.

Serviceability 3
Tip-Up Cab and Easy Checkpoints

The entire cab tips up for maintenance, engine checkpoints are within easy reach, and most service items can be accessed without raising the lift arm.

Protected Battery and Maintenance-Free Chaincase

The battery sits under the cab with a remote jumpstart terminal in the engine compartment, and the welded-axle chaincase never needs chain adjustment.

Dealer Parts & Service Support

Carleton Equipment support helps keep filters, fluids, wear parts, attachments and planned maintenance available for the S66.

Bobcat S66 Skid-Steer Loader

Why Buyers Choose the S66

74 hp and 2,400 lb ROC for buyers who want more lift capacity in a compact R-Series skid-steer

4,800 lb tipping load and 120 in hinge-pin height support loading, carrying and material handling

Optional high-flow hydraulics up to 26.9 gpm expand attachment capability

Standard two-speed travel reaches up to 11 mph for quicker movement across yards, lots and jobsites

Standard Super Float tires deliver precision turning and skidding with minimal soil disturbance

Inline engine, direct-drive system, cast-steel lift arms and improved cooling support long workdays

Customers & Applications

Who Uses the S66 and What For

The S66 is an R-Series skid-steer loader for crews that want stronger rated operating capacity, standard two-speed travel and a comfortable clear-side cab on paved, improved and hard-packed surfaces.

Construction & Utility Work

  • Grading, backfilling, trench support and site cleanup
  • Moving aggregate, pallets, spoil, debris and jobsite materials
  • Running augers, breakers, trenchers, buckets, forks and grapples
  • Working where lift capacity and compact skid-steer maneuvering both matter

Landscape & Grounds Crews

  • Preparing hardscape bases and spreading soil, stone or mulch
  • Using soil conditioners, brush tools, grading attachments and snow tools
  • Handling repeated load-and-carry work on firm improved surfaces
  • Moving quickly between tasks with standard two-speed travel

Rental & Fleet Owners

  • Proven R-Series platform with dealer parts and service support
  • Standard or SJC controls and Features on Demand simplify fleet configuration
  • Optional high flow supports a wider attachment rental mix
  • Supported by Carleton Equipment parts, service and attachment expertise
Skid-Steer Loaders

Two Paths: Classic or Pro

Not sure which tier fits your application? Compare the full loader lineup side by side.

Explore the Lineup
Pro Loader Packages

Find the Right Package for the Way You Work

Package options make it easier to choose the right mix of advanced comfort, control and technology for the way you work. Compare package levels below to find the Pro Bobcat loader setup that matches your jobsites, applications and operator preferences.

Request a Quote Download Full Package Guide

WORK, CORE, PLUS and ADVANCED packages are available across Pro Bobcat loaders.

Work Core Plus Advanced
Overview
Summary Pro control and operation at a competitive price. Pro control and operation with upgraded comfort and performance options. Pro control and operation with premium comfort and performance standard. Plus package with Jobsite Companion.
Standard Features
Power Bob-Tach® ✔ ✔ ✔ ✔
Keyless Ignition ✔ ✔ ✔ ✔
7-Pin Attachment Control ✔ ✔ ✔ ✔
2-Speed ✔ ✔ ✔ ✔
Auto-Throttle ✔ ✔ ✔ ✔
Dual-Direction Bucket Positioning ✔ ✔ ✔ ✔
Bluetooth Radio ✔ ✔ ✔ ✔
Main Package Differences
Suspension Seat Vinyl High-Back Heated Cloth Air-RideWith Enclosed Cab High-Back Heated Cloth Air-Ride High-Back Heated Cloth Air-Ride
Display 8" 8" w/ InfotainmentWith Enclosed Cab 8" w/ Infotainment 8" w/ Infotainment
Lights LED Premium LED Premium LED w/ Side Lights Premium LED w/ Side Lights
Machine IQ Telematics 2YR Basics 2YR Basics 1YR H&S + 1YR Basics 1YR H&S + 1YR Basics
Automatic Ride Control — ✔ ✔ ✔
Sound Reduction — ✔With Enclosed Cab ✔ ✔
Jobsite Companion — — — ✔
Package Options
Cab Open or Enclosed HVAC Open or Enclosed HVAC Enclosed HVAC W/ Clear-Side Enclosure Enclosed HVAC W/ Clear-Side Enclosure
Controls SJC STD
Hand & Foot OPT		 SJC STD
Hand & Foot OPT		 SJC STD
Hand & Foot OPT		 SJC
Camera(s) Rear View Rear View Rear View STD
Broad Area OPT		 Rear View STD
Broad Area OPT
Undercarriage Solid Mount Solid Mount Solid Mount Solid Mount
Auxiliary Flow Standard Flow Standard Flow STD
Standard+High OPT		 Standard+High STD Standard+High STD
Reversing Fan — Included w/ High Flow ✔ ✔
Bobcat Sense Rear Object Detection and Avoidance OPT Rear Object Detection and Avoidance OPT Rear Object Detection and Avoidance OPT 360 People Detection OPT
Tracks C-Pattern 12.6" STD
C-Pattern 15.7" OPT
MBL 15.7" OPT		 C-Pattern 12.6" STD
C-Pattern 15.7" OPT
MBL 15.7" OPT		 C-Pattern 12.6" STD
C-Pattern 15.7" OPT
MBL 15.7" OPT		 C-Pattern 12.6" STD
C-Pattern 15.7" OPT
MBL 15.7" OPT
STD Included standard OPT Available as an add-on "With Enclosed Cab" — feature level varies based on cab selection

Full Specifications

General
ConditionRental
Machine TypeSkid Steer Loader
Engine
Engine MakeBobcat
Horsepower74.0
EmissionsTier 4
Performance
Rated Operating Capacity2,400 lb
Bucket Hinge Pin Height120 in.
Tipping Load4,800 lb
Travel Speed7.4-11 mph
Capacities
Fuel Tank28.3 gal.
Hydraulics
Auxiliary Std Flow17.6 GPM
Auxiliary High Flow26.9 GPM
Dimensions & Weight
Height80.5 in.
Length135 in.
Width67 in.
Operating Weight7154 lb
Wheelbase44.6 in.
Turning Radius80.1 in.
Serviceability

Specifications subject to change without notice. Contact your local Carleton Equipment dealer to confirm details.
