Rent a Bobcat L28 Articulating Loader - Bobcat Rental in Michigan
The L28 Bobcat® small articulated loader delivers big performance and heavy lifting in a small package.
- Easily works inside fenced-in landscapes, pens, backyards and more.
- Impressive lifting capacity and telescoping lift arm
- Tight-turning articulation joint
- Power Bob-Tach System
Specs
Key Specs
| Horsepower |
24.8 hp |
| Rated Operating Capacity Straight (ISO) |
1,534 lb |
| Rated Operating Capacity Articulated |
1,222 lb |
| Operating Weight |
4,195 lb |
| Auxiliary Standard Flow |
12.1 gal/min |
| Width (Over Tires) |
46.5 in |
| Max Reach |
30.9 in |
| Height to Bucket Hinge Pin Extended |
104.3 in |
Engine
| Emissions Tier (EPA) |
Tier 4 |
| Engine Cooling |
Liquid |
| Engine Fuel |
Diesel |
| Horsepower |
24.8 hp
|
| Turbocharged Engine |
No
|
Performance
| Rated Operating Capacity Straight (ISO) |
1,534 lb |
| Rated Operating Capacity Articulated (ISO) |
1,222 lb |
| ROC with Counterweight - Straight |
1,952 lb |
| ROC with Counterweight - Articulated |
1,475 lb |
| Tipping Load - Straight |
3,068 lb |
| Tipping Load - Articulated |
2,444 lb |
| Operating Weight |
4,195 lb |
| Travel Speed |
8.3 mph |
Capacities
Hydraulic System
| Auxiliary Std Flow |
12.1 gal/min |
| System Relief @ Quick Couplers |
2,900 psi |
Dimension
| Length |
122.4 in |
| Length without Attachment |
93.2 in
|
Length with Standard Bucket
|
122.4 in
|
| Width (Over Tires) |
46.5 in |
| Width (With Bucket) |
50 in |
| Height with Operator Cab |
78.1 in |
| Height to Bucket Hinge Pin Extended |
104.3 in |
| Height to Bucket Hinge Pin Retracted |
85.4 in |
| Max Reach |
30.9 in |
| Turning Radius Inside |
78.2 in |
| Turning Radius Outside |
100.9 in |
| Wheelbase |
47.2 in |
| Articulation Angle |
43° |
| Dump Angle @ Maximum Height |
40° |
| Ground Clearance |
5.5 in |
| Rollback Angle |
32° |
| Tire Size |
23X10.5-12 8 PLY |
| Wheel Tread |
36.4 in |
