- Horsepower
- 49.7 hp
- Max dig depth
- 11.4 ft
- Operating weight
- 11,876 lb
- Bucket digging force
- 9,511 lbf
More specifications
|
General Info
|
|
|---|---|
| Condition: | Rental |
| Manufacturer: | Bobcat |
| Model: | E50 |
| Machine Type: | Mini Excavator |
| Coupler: | X-CHANGE |
|
Engine
|
|
|---|---|
| Horsepower: | 49.7 |
|
Performance
|
|
|---|---|
| Bucket Digging Force: | 9,511 LBF. |
| Arm Digging Force: | 5,962 LB. |
| Max Digging Reach (Ground): | 19.4 FT. |
| Max Digging Depth: | 11.4 FT. |
| Operating Weight: | 11876 lb |
|
Hydraulics
|
|
|---|---|
| Aux. Standard Flow: | 20 GPM |
|
Dimensions
|
|
|---|---|
| Width: | 77.2 IN. |
| Fuel Tank: | 19 GAL |
Description
Rent a Bobcat E50 Mini Excavator - Bobcat Rental in Michigan
Rental Rates
The minimal tail swing E50 compact excavator delivers the performance and comfort features to take productivity to the next level.
- Enhanced hydraulic performance
- Redesigned Bobcat engine
- Improved cooling system
Specs
Key Specs
| Specs | E50 | E50 - Long Arm | E50 - Extendable Arm |
| Operating Weight | 11,876 lb | 11,984 lb | 11,876 lb |
| Bucket Digging Force | 9,511 lbf | 9,511 lbf | 9,511 lbf |
| Maximum Reach at Ground Level | 232.8 in | 247.2 in | 232.8 in |
| Width | 77.2 in | 77.2 in | 77.2 in |
| Tail Swing Type | Minimal |
Minimal | Minimal |
Engine
| Specs | E50 | E50 - Long Arm | E50 - Extendable Arm |
| Emissions Tier |
Tier 4 |
Tier 4 | Tier 4 |
| Engine Fuel |
Diesel |
Diesel | Diesel |
| Maximum Governed RPM |
2,200 RPM |
2,200 RPM | 2,200 RPM |
| Horsepower | 49.7 | 49.7 | 49.7 |
| Turbocharged Engine |
Yes |
Yes | Yes |
Performance
| Specs | E50 | E50 - Long Arm | E50 - Extendable Arm |
| Operating Weight | 11,876 lb | 11,894 lb | 11,876 lb |
| Weight Class |
5.1 Ton |
5.3 Ton | 5.1 Ton |
| Travel Speed - High |
2.8 mph |
2.8 mph | 2.8 mph |
| Travel Speed - Low |
1.8 mph |
1.8 mph | 1.8 mph |
| Arm Digging Force |
6,987 lbf |
5,962 lbf | 6,987 lbf |
| Bucket Digging Force | 9,511 lbf | 9,511 lbf | 9,511 lbf |
| Lift Radius | 118 in | 118 in | 118 in |
| Boom Swing - Left | 75° | 75° | 75° |
| Boom Swing - Right | 50° | 50° | 50° |
| Maximum Dig Depth | 136.8 in | 152.4 in | 136.8 in |
| Max Dump Height | 156 in | 166.8 in | 156 in |
| Maximum Reach at Ground Level | 232.8 in | 247.2 in | 232.8 in |
Capacities
| Specs | E50 | E50 - Long Arm | E50 - Extendable Arm |
| Fuel Tank | 19 gal | 19 gal | 19 gal |
Hydraulic System
| Specs | E50 | E50 - Long Arm | E50 - Extendable Arm |
| Auxiliary Standard Flow |
20 gal/min |
20 gal/min | 20 gal/min |
| Auxiliary Pressure | 3,045 psi | 3,045 psi | 3,045 psi |
Dimensions
| Specs | E50 | E50 - Long Arm | E50 - Extendable Arm |
| Length |
208.7 in |
211.3 in | 208.7 in |
| Overall Length in Travel Position | 208.7 in |
211.3 in | 208.7 in |
| Width | 77.2 in | 77.2 in | 77.2 in |
| Height | 100.2 in | 100.2 in | 100.2 in |
What Makes the E50 Different
49.7 HP Redesigned Bobcat Engine
The E50 is powered by a 49.7-horsepower, redesigned Bobcat engine paired with an improved cooling system that enhances performance, serviceability and component life. Fast cycle times keep this R2-Series excavator productive through long days of digging and loading.
Strong Digging & Lifting Performance
With 9,511 lbf of bucket digging force, 6,987 lbf of arm digging force and 11.4 ft of dig depth on the standard arm, the E50 handles trenching, footings and heavy loading with confidence. A 13 ft maximum dump height makes it easy to load trucks and dumpsters.
Minimal Tail Swing & Deep Reach
Less than one inch of tail swing overhang (0.6 in) lets the E50 work close to walls, foundations and other obstacles in tight areas, while 19.4 ft of reach at ground level and 75 degrees of boom swing to the left and 50 degrees to the right let operators dig farther with fewer repositioning moves.
Selectable Auxiliary Hydraulic Flow
Standard auxiliary hydraulics deliver 20 gpm of flow at 3,045 psi with selectable flow control, and the standard Quick-Tach system speeds up attachment changes so one machine covers a wide range of jobsite tasks.
Precise, Low-Effort Control
Low-effort joysticks respond easily to operator input, and hydraulic control provides better metering, finite movement and controllability on level grading, so operators can work accurately with less fatigue.
E50 Features & Benefits
Performance 3
Redesigned Bobcat Engine
The redesigned 49.7 hp Bobcat engine on the R2-Series E50 delivers enhanced hydraulic performance and improved efficiency, backed by an improved cooling system that enhances performance, serviceability and component life.
Long-Arm Option
The E50 can be equipped with a long arm to increase dig depth and reduce the frequency of repositioning, so operators cover more trench from each setup.
Angle Blade
The optional angle blade lets you position the blade to the left or right to find the best angle for backfilling and grading, helping you finish work faster with fewer passes.
Control 2
Low-Effort Joysticks
Low-effort joysticks on R2-Series excavators respond easily to operator input, helping operators work longer with less fatigue and more precise movement.
Precise Hydraulic Control
Hydraulic control on the E50 provides better metering, finite movement and controllability on level grading, with fast cycle times when the job calls for speed.
Comfort & Visibility 3
Touch Display
An optional state-of-the-art touch display puts machine information at the operator's fingertips from inside the cab.
Automatic Heat & Air Conditioning
Optional automatic heat and air conditioning, cab enclosure, cab heater and radio keep operators comfortable through Michigan winters and summers alike.
Rearview Camera
An optional rearview camera gives the operator an additional view of the area behind the machine while working in tight areas.
Serviceability 2
Improved Cooling System
The improved cooling system on the R2-Series E50 enhances performance, serviceability and component life for more uptime on the jobsite.
Simplified Maintenance
Simplified maintenance on the redesigned Bobcat engine helps keep routine service quick, and Carleton Equipment's parts and service teams keep the E50 working for years to come.
Why Buyers Choose the E50
49.7 hp redesigned Bobcat engine with strong digging forces, 9,511 lbf bucket and 6,987 lbf arm
11.4 ft dig depth and 19.4 ft reach at ground level on the standard arm, with a long arm available for deeper work
Minimal tail swing with 0.6 in overhang helps operators work close to walls, foundations and other obstacles
20 gpm auxiliary flow at 3,045 psi with selectable flow control and standard Quick-Tach attachment system
Low-effort joysticks and hydraulic control deliver better metering and precise movement on level grading
5-ton class at 77.2 in wide, with optional cab enclosure, automatic heat and A/C, rearview camera and angle blade
Who Uses the E50 and What For
The Bobcat E50 is a 5-ton-class R2-Series compact excavator built for contractors who need serious digging depth and force in a machine with minimal tail swing. With 20 gpm of selectable auxiliary flow and precise, low-effort controls, it moves from trenching and foundation work to attachment-driven tasks in tight areas.
Excavation & Site Work
- Digging footings and foundations
- Trenching and backfilling
- Level grading with precise hydraulic control
- Loading spoil into trucks and dumpsters
Utility & Underground
- Water, sewer and storm line installation
- Electrical and gas conduit trenching
- Deeper utility runs with the optional long arm
- Working close to structures with minimal tail swing
Rental & Fleet Owners
- Proven platform with dealer parts and service support
- Standard auxiliary hydraulics and Quick-Tach fit a broad range of attachments
- Low-effort joysticks help operators of all experience levels get productive quickly
Talk to a person about the E50
Carleton Equipment is a family-owned Michigan dealer, here since 1938. Sales, rental, service and parts all come from the same team, and we’ll connect you with the location nearest you.
- Chesterfield
- Coldwater
- Grand Rapids
- Howell
- Kalamazoo
- Livonia
- Saginaw
Full Specifications
General
| Condition | Rental |
| Machine Type | Mini Excavator |
Engine
| Engine Make | Bobcat |
| Horsepower | 49.7 |
Performance
| Dig Depth | 11.4 FT. |
| Max Reach at Ground Level | 19.4 FT. |
| Bucket Digging Force | 9,511 LBF. |
| Arm Digging Force | 5,962 LB. |
Capacities
| Fuel Tank | 19 GAL |
Hydraulics
| Auxiliary Std Flow | 20 GPM |
Dimensions & Weight
| Width | 77.2 IN. |
| Operating Weight | 11876 lb |
Serviceability
Specifications subject to change without notice. Contact your local Carleton Equipment dealer to confirm details.
|
