Rent a Bobcat E35 Mini Excavator - Bobcat Rental in Michigan
Rental Rates
Daily |
Weekly |
Monthly |
$350
|
$1,200 |
Call for Pricing Plans |
The E32 features unmatched power and a narrow stance.
- Powerful performance and maneuverability
- Conventional tail swing
- Ideal for restrictions like doors and gates
- Various arm options
Specs
Key Specs
Specs |
E35 (25 hp) |
E35 (25 hp) - Long Arm |
E35 (25 hp) - Extendable Arm |
Operating Weight |
7,659 lb |
8,362 lb |
8,590 lb |
Bucket Digging Force |
7,284 lbf |
7,284 lbf |
7,284 lbf |
Maximum Reach at Ground Level |
204.3 in |
215.8 in |
235.1 in |
Width |
69.7 in |
69.7 in
|
69.7 in
|
Tail Swing Type |
Zero
|
Minimal |
Minimal |
Engine
Specs |
E35 (25 hp) |
E35 (25 hp) - Long Arm |
E35 (25 hp) - Extendable Arm |
Emissions Tier
|
Tier 4
|
Tier 4 |
Tier 4 |
Engine Fuel
|
Diesel
|
Diesel |
Diesel |
Maximum Governed RPM
|
2,450 RPM
|
2,450 RPM |
2,450 RPM |
Turbocharged Engine
|
No
|
No |
No |
Performance
Specs |
E35 (25 hp) |
E35 (25 hp) - Long Arm |
E35 (25 hp) - Extendable Arm |
Operating Weight |
7,659 lb |
8,362 lb |
8,590 lb |
Weight Class
|
3.5 Ton
|
3.8 Ton |
3.9 Ton |
Travel Speed - High
|
2.9 mph
|
2.9 mph
|
2.9 mph |
Travel Speed - Low
|
1.6 mph
|
1.6 mph |
1.6 mph |
Arm Digging Force
|
4,690 lbf
|
4,074 lbf |
4,592 lbf |
Bucket Digging Force |
7,284 lbf |
7,284 lbf |
7,284 lbf |
Lift Radius |
118 in |
118 in |
118 in |
Boom Swing - Left |
75° |
75° |
75° |
Boom Swing - Right |
55° |
55° |
55° |
Maximum Dig Depth |
121.2 in |
133 in |
153.2 in |
Max Dump Height |
137.2 in |
144.3 in |
154.5 in |
Maximum Reach at Ground Level |
204.3 in |
215.8 in |
235.1 in |
Capacities
Specs |
E32 |
E32 - Long Arm |
E32 - Extendable Arm |
Fuel Tank |
13.7 gal |
13.7 gal |
13.7 gal |
Hydraulic System
Specs |
E32 |
E32 - Long Arm |
E32 - Extendable Arm |
Auxiliary Standard Flow
|
16.9 gal/min
|
16.9 gal/min |
16.9 gal/min |
Auxiliary Pressure |
2,987 psi |
2,987 psi |
2,987 psi |
Dimensions
Specs |
E32 |
E32 - Long Arm |
E32 - Extendable Arm |
Length
|
190 in
|
190.1 in |
190.4 in |
Overall Length in Travel Position |
190 in
|
190.1 in |
190.4 in |
Width |
69.7 in |
69.7 in |
69.7 in |
Height |
96.2 in |
96.2 in |
96.2 in |
