Bobcat E26 - Rental

Based on 7 day Rental - As low as*- Daily - $171
Online Estimate:
Sale price$171.00 /Daily*
Stock:
In stock
General Info
Condition: Rental
Manufacturer: Bobcat
Model: E26
Machine Type: Mini Excavator
Coupler: X-CHANGE
Engine
Horsepower: 24.8
Performance
Bucket Digging Force: 5,652 LBF.
Arm Digging Force: 3,547 LB.
Max Digging Reach (Ground): 16 FT.
Max Digging Depth: 9.5 FT.
Operating Weight: 6489 lb
Hydraulics
Aux. Standard Flow: 14.2 GPM
Dimensions
Width: 61 IN.
Fuel Tank: 9.1 GAL

Description

Rent a Bobcat E26 Mini Excavator - Bobcat Rental in Michigan

Rental Rates

The minimal tail swing E26 handles big jobs in tight quarters.

  • Minimal tail swing
  • Compact size with minimal ground disturbance
  • Standard long arm configuration
Specs

Engine

Emissions Tier (EPA) Tier 4
Engine Cooling Liquid
Engine Fuel Diesel
Horsepower 24.8
Turbocharged Engine

No

Performance

Operating Weight
6,489 lb
Weight Class
2.9 Ton
Travel Speed - High
3.2 mph
Travel Speed - Low
1.8 mph
Arm Digging Force 3,547 lbf
Bucket Digging Force 5,652 lbf
Rated Lift Capacity 2,359 lb
Lift Radius 118 in
Boom Swing - Left 70°
Boom Swing - Right 55°
Maximum Dig Depth 114.4 in
Max Dump Height 129.6 in
Maximum Reach at Ground Level 192 in

Capacities

Fuel Tank 9.1 gal

Hydraulic System

Auxiliary Std Flow 14.2 gal/min
Auxiliary Pressure 2,611 psi

Dimension

Length 170.4 in
Overall Length in Travel Position 170.4 in
Width 61 in
Height 96 in
Height with Operator Cab 96 in
Tail Swing Type Minimal
    Bobcat Compact Excavators

    Compare the MX Family

    Bobcat E10 Bobcat E17 Bobcat E20 Bobcat E26 Bobcat E32 Bobcat E35 Bobcat E38 Bobcat E40
    E10 E17 E20 E26Viewing E32 E35 E38 E40
    Specifications
    Tail Swing Overhang Zero Zero 0 in 3.5 in 16.9 in 3.2 in 3.2 in 1.6 in
    Operating Weight 2,593 lb 3,774 lb 4,167 lb 6,489 lb 8,497 lb 8,362 lb 7,893 lb 9,180 lb
    Horsepower 10.2 hp 15.0 hp 15.0 hp 24.8 hp 24.8 hp 24.8 hp 33.2 hp 40.4 hp
    Rated Lift Capacity 965 lb 807 lb 1,382 lb 2,359 lb 2,733 lb 3,206 lb 3,318 lb 3,939 lb
    Aux Hydraulic Flow 5.3 gpm 7.9 gpm 7.9 gpm 14.2 gpm 16.9 gpm 16.9 gpm 16.9 gpm 16.9 gpm
    Bucket Digging Force 1,865 lbf 4,121 lbf 4,121 lbf 5,652 lbf 7,284 lbf 7,284 lbf 7,284 lbf 7,284 lbf
    Max Dig Depth 60 in 87.8 in 100.2 in 114.4 in 153.2 in 133 in 133.2 in 130.8 in
    Max Reach at Ground Height 122.4 in 154.8 in 169.2 in 192 in 225.3 in 215.8 in 204 in 215.2 in
    Max Dump Height 60 in 98 in 110.2 in 128.8 in 154.5 in 144.3 in 136.8 in 150 in
    Width
    *E10–E20 w/ blade retracted
    28 in 38.6 in 38.6 in 61 in 61.8 in 69.7 in 69.7 in 72.8 in
    Travel Speed
    (High/Low)
    1.7/1.7 mph 1.2/2.5 mph 1.3/2.5 mph 3.2/1.8 mph 2.9/1.6 mph 2.9/1.6 mph 2.9/1.6 mph 3.2/1.6 mph

    Specifications subject to change without notice.

    E26

    E26 Features & Benefits

    Performance 6
    2-Speed Travel

    Maneuver faster with the Bobcat 2-Speed option. The quicker you can move on your jobsite, the faster you can complete your work. Select low range for pushing and dozing and high range for increased jobsite mobility.

    Auto Shift

    Auto-Shift travel shifts the machine out of high range and back automatically, offering superb travel performance without having to manually downshift. It automatically transitions the travel motors to and from high range, giving you greater tractive effort with no manual shifting. Simply select the travel speed range and go. A directional lug track also provides a smoother ride and less vibration when traveling.

    Fingertip Boom Swing Control

    Bobcat® excavator controls allow you to make fine movements with low effort and maximum comfort – so you can get precise results in less time, with less fatigue. A rocker-style thumb switch, located on the left joystick, provides superior boom swing control with better metering than foot pedals. Multifunction operation, such as swinging and traveling simultaneously, is also easier. With the boom swing control on the joystick, you get more floor space and foot room that provides a comfort advantage on long, tiring jobs.

    Advanced Hydraulics

    Whether you're traveling across a jobsite, backfilling, or digging, your excavator's hydraulic system contributes to performance more than any other feature. When compared to other brands, advanced hydraulics on Bobcat® excavators deliver the most horsepower in working range.

    Predictable Control

    Bobcat® compact excavators deliver the house, boom, arm and bucket control you expect in the most challenging work environments. It's the confidence in these precise movements that determines whether you complete the job using your machine, or with two workers and a pair of shovels.

    Blade Float

    Simplify grading and leveling. Blade float exerts a minimal, consistent down-force on the blade, with minimal operator input.

    Comfort 2
    Premium Cab

    Premium comfort gives you the endurance to power through long days and tough jobs. When you step inside the Bobcat compact excavator cab, you'll see refinements everywhere you look, including plenty of headroom and legroom, clear visibility, and a larger suspension seat. Each feature has been designed to help keep you working all day long.

    Auto Idle

    Auto Idle makes it easier and quieter to pause your work, take a quick break or communicate on the jobsite — all while saving fuel. When machine functions aren't used, the machine automatically idles the engine until you start working again.

    Uptime Protection 7
    In-Track Swing Frame

    The exclusive In-Track Swing Frame on Bobcat® compact excavators gets you closer to your work. When you dig in an offset position, the swing castings and cylinders remain within the tracks to help you work in small spaces. You can dig flush against an obstacle, minimizing the chances of inadvertent contact and reducing operating costs of repairs to your machines or adjacent structures. Other brands cannot match this feature: when they work in an offset digging position, their components extend outside the tracks and reduce their ability to dig in tight areas.

    Protected Components

    No other manufacturer provides so many job-proven features to give you more uptime in the field. Bobcat® steel hydraulic lines offer better protection than rubber hoses — routed through the lower portion of the boom swing casting and tucked securely into the top area of the boom structure, preventing costly damage and protecting component life. The boom, arm and attachment/bucket offer better lifting performance and longer durability. Cast pivot joints provide precise pin alignment which lengthens the service life of pivot pins and bushings. A strong, lightweight composite door on cab models withstands years of tough work.

    Simple Machine Tie-Down

    Get on and off the jobsite faster. Secure your load quickly, without searching for hard-to-reach tie-downs.

    Integrated Slew Brakes

    Integrated slew brakes hold your load steady on slopes for more accurate placement. It's easier to position the excavator, and you no longer need to manually engage the slew brake during transport.

    X-Frame Undercarriage

    With better ground clearance, the X-frame undercarriage improves your performance in difficult conditions. Dirt and other materials easily pass through this undercarriage, making cleanup faster and leaving less debris on trailers. The X-frame design places drive motors within the width of the tracks, protecting the assembly and improving agility in soft conditions. Recessed motor covers eliminate potential damage and improve your uptime on the job.

    Protection Technology

    Bobcat controls and electrical systems are engineered with more watertight, corrosion-resistant connectors than other manufacturers' machines.

    Multiple Tailswing Configurations

    Choose an excavator model with the tail swing configuration that best matches the needs of your jobsite. Conventional Tail Swing models deliver the greatest lift capacity and a narrower stance for easier trailer loading and better access through tight areas. Minimal Tail Swing provides more maneuverability than conventional tail swing, with the rear of the house protruding no more than 6 in. beyond the width of the tracks. Zero Tail Swing (ZTS) keeps the rear of the house within the width of the tracks through full rotation, giving you the most unrestricted rotation for working close to objects or against a wall.

    Serviceability 1
    Panoramic Serviceability

    Maintenance is necessary, and Bobcat compact excavators are designed to make it easy. A wide opening gives you more space to work, while a smart layout gives you access to critical components. Access engine and pump package, valve bank, cooling system and plumbing using the swing-open tailgate and side access hood. Filters, fluid checks, air cleaner, battery and other maintenance points are simple to access. A multi-groove auto-tensioning belt made of tough DuPont Kevlar® requires no adjustment, making maintenance much easier. Fewer 90-degree fittings result in more efficient hydraulic fluid transfer and better utilization of engine horsepower. A centralized grease bank makes fast, simple work of lubricating the slew bearing and slew pinion.

    Digital Connectivity 1
    Machine IQ

    Available in the Owner Portal and Machine IQ mobile app, Machine IQ telematics lets you monitor your machine's location, health, and security status so you're always in control. Protect your equipment with remote engine disable/enable, geofence boundaries, motion detection and curfew alerts that notify you when unauthorized activity occurs. Reduce downtime with proactive critical fault code notifications and maintenance reminders that keep you ahead of potential issues.

    E26 Configuration

    Arm Options

    Choose the arm configuration that best matches your work.

    Not Available

    Standard Arm

    Provides maximum breakout force and lifting ability. The best choice when power and digging performance are the priority.

    Standard on E26

    Long Arm

    Gives you longer reach and more dig depth. Ideal when you need to work farther from the machine or dig deeper trenches.

    Not Available

    Extendable Arm

    Delivers the power and performance of a standard arm with extra reach on demand — up to 2 feet greater than the long arm, depending on the model.

    E26 Key Performance — Long Arm Configuration

    Working Dimensions
    Dig Depth
    114 in
    Max Reach
    192 in
    Dump Height
    129 in
    Digging Forces
    Bucket Force
    5652 lbf
    Arm Force
    3547 lbf

    Specifications subject to change without notice.

    Full Specifications

    General
    ConditionRental
    Machine TypeMini Excavator
    Engine
    Engine MakeKubota
    Horsepower24.8
    EmissionsTier 4
    Performance
    Travel Speed3.2 / 1.8 mph
    Dig Depth9.5 FT.
    Max Reach at Ground Level16 FT.
    Max Dump Height128.8 in
    Lift Radius118 in
    Bucket Digging Force5,652 LBF.
    Arm Digging Force3,547 LB.
    Boom Swing70° left / 55° right
    Hydraulics
    Aux. Standard Flow14.2 GPM
    Relief Pressure2,611 psi
    Dimensions & Weight
    Height96 in
    Length170.4 in
    Width61 IN.
    Operating Weight6489 lb
    Tail Swing Overhang3.5 in (Minimal)
    Fuel Tank9.1 GAL
    Features
    Tail Swing TypeMinimal
    Auxiliary Hydraulics■ Standard
    Rubber Track■ Standard
    Cab Enclosure○ Optional
    Cab Heater○ Optional
    Air Conditioning○ Optional
    Radio○ Optional
    Quick Tach System■ Standard
    Selectable Aux. Flow■ Standard
    Angle Blade— Not Available

    Specifications subject to change without notice. Contact your local Carleton Equipment dealer to confirm details.
