Bobcat® Grapple, Utility - Loaders & Toolcat
Description
Sink into hard-to-handle light materials or farm materials with the bite of the utility grapple attachment.
The utility grapple offers the additional holding ability necessary to bite down on even the loosest materials. Designed with efficiency in mind, the compact design of the utility grapple gets the fork or bucket close to fences or the sides of stalls for maximum material moving.
Choose from a fork and grapple, or bucket and grapple to handle a wide variety of farm and ranch jobs. Whether home on the range or down on the farm, the utility grapple sinks in to get the job done.
Top Tasks
- Lift, and move loose materials such as manure, bedding, and hay
- Grip posts, fencing and other hard-to-manage materials
Features
- Curved Teeth: Help pull materials into the grapple, scooping up even the loosest material. Also, teeth are replaceable for added uptime protection.
- Forged Teeth: Provide exceptional strength with low weight, allowing for more carrying capacity.
- Provisions for Additional Teeth: Easier to handle smaller materials.
Specs
General
| Operating Weight | 157 lb | 157 lb | 180 lb | 243 lb |
| Length | 31.6 in | 31.7 in | 32.7 in | 34.8 in |
| Width | 35.1 in | 35.1 in | 58 in | 58 in |
| Height | 28.8 in | 29.5 in | 29.4 in | 29.9 in |
| Number of Fork Teeth (Factory) | 3 | 3 | 4 | 4 |
| Number of Fork Teeth (Possible) | 5 | 5 | 8 | 8 |
| Grapple Width | 32 in | 32 in | 55 in | 55 in |
| Number of Grapple Tines | 3 | 3 | 4 | 4 |
| Open Height | 41.7 in | 42.5 in | 41.9 in | 42.3 in |
| Open Length | 35.6 in | 35.7 in | 38.6 in | 40.1 in |
| Closed Height | 28.8 in | 29.5 in | 29.4 in | 29.9 in |
| Closed Length | 31.6 in | 31.7 in | 32.7 in | 34.8 in |
Compatible Carriers
| Skid-Steer Loaders |
| Bobcat A770 | ✅ | |||
| Bobcat S70 | ✅ | ✅ | ||
| Bobcat S450 | ✅ | |||
| Bobcat S550 | ✅ | ✅ | ||
| Bobcat S570 | ✅ | ✅ | ||
| Bobcat S590 | ✅ | |||
| Bobcat S595 | ✅ | |||
| Bobcat S630 | ✅ | |||
| Bobcat S650 | ✅ | |||
| Bobcat S740 | ✅ | |||
| Bobcat S770 | ✅ |
| Compact Track Loaders |
| Bobcat T450 | ✅ | |||
| Bobcat T550 | ✅ | |||
| Bobcat T590 | ✅ | |||
| Bobcat T595 | ✅ | |||
| Bobcat T630 | ✅ | |||
| Bobcat T650 | ✅ |
| Toolcat™ Work Machine |
| Bobcat 5600 | ✅ | ✅ | ||
| Bobcat 5610 | ✅ | ✅ |
| Mini Track Loaders |
| Bobcat MT55 | ✅ | ✅ | ||
| Bobcat MT85 | ✅ | ✅ |
