Description
AlphaPlow by SnowWolf
For: 14,000-30,000 lb. Machinery
Description
In a wolf pack, the alpha male is king. The one who does all of the work, with the most wind in his face, and breaks the trail for his followers. Hence, the Alpha Series Snow Plow – the biggest, meanest SnowWolf yet.
Specifications
| Model Number | Alpha-10.0 | Alpha-12.0 | |
| Blade Width | 10' | 12' | |
| Blade Width at Full Angle | 98.3" | 118" | |
| Blade Height | 38" | 38" | |
| Weight (lbs.) (actual-not ship weight) | 1,920 | 2,217 | |
| Moldboard Gauge | 10 ga. | 10 ga. | |
| Trip Spring | 8 Ext | 8 Ext | |
| Wear Shoes | N/A | N/A | |
| Cutting Edge | 3/4" x 8" | ||
| Angle Rams | 2" x 13" Double Acting, Nitro Steel Cylinder | ||
| Vertical Ribs | 8 | 10 | |
| Moldboard Radius | 19" | 19" | |
| Full Down Pressure | Floating / Full | ||
| Universal Skid Steer Compatible | N/A | N/A | |
| Cross Over Relief Valve | Std. | Std. | |
| SoftTouch™ Cutting Edge | Opt. | Opt. | |
| UltraMAX HD Cylinder Kit | N/A | N/A | |
| High Carbon Curb Guards | N/A | N/A | |
Features
| Features | Benefits |
|---|---|
| Dual Pivot A-Frame | Twice the strength, half the worries! |
| Massive Construction | Designed for abuse from larger equipment, the AlphaPlow blade features continuous welded construction and weights of 185 per foot. |
| Trip Edge | Protects machine and operator from hidden obstacles. Our trip edge is in two sections, so the whole blade doesn't need to trip and full down pressure can we applied. |
| New Floating Loader Mounts | Options available for most wheel loaders, including CAT Fusion, CAT IT, JRB 416 and more. |
