Bobcat T650 Series - Rental
Bobcat T650 Series - Rental
Bobcat T650 Series - Rental
Bobcat T650 Series - Rental
Roll over image to zoom in Click on image to zoom
Bobcat T650 Series - RentalBobcat T650 Series - RentalBobcat T650 Series - RentalBobcat T650 Series - Rental

Bobcat T650 Series - Rental

Bobcat
Based on 7 day Rental - As low as*- Daily - $185
Online Estimate:
$185.00 /Daily*
Stock:
In stock
General Info
Condition: Rental
Manufacturer: Bobcat
Model: T650
Machine Type: Compact Track Loader
Coupler: Bob-Tach
Engine
Horsepower: 74.0
Emissions: Tier 4
Performance
Rated Operating Capacity (ISO): 2,570 lb
Tipping Load: 7,343 lb
Operating Weight: 9113 lb
Travel Speed: 6.2-8.7 mph
Height to Bucket Hinge Pin: 124 in.
Hydraulics
Aux. Standard Flow: 23 GPM
Dimensions
Height: 81.3 in.
Length: 108.4 im
Width: 72.9 in.
Fuel Tank: 43.9 gal.

Description

Bobcat T650 Series - Rental

The Bobcat T650 Series - Rental is an exceptional compact track loader designed to help you tackle tough jobs with maximum efficiency. Powered by a robust 74 HP diesel engine, it offers a rated operating capacity of 2,570 lb and a tipping load of 7,343 lb. With a vertical lift arm path and a 124-inch bucket hinge pin, you'll enjoy impressive reach and height for demanding tasks. Its 12.6-inch tracks enhance stability and reduce ground disturbance, while the convenient Bob-Tach coupler system provides secure and rapid attachment changes. The T650 handles speeds up to 8.7 mph for swift operation, bringing power and productivity to your jobsite.

Description

The Bobcat® T650 strikes an impressive balance, providing excellent lift capabilities, fast cycle times and powerful breakout forces that Bobcat is known for, but with simplified options and configurations.

Specs

Engine

Emissions Tier (EPA) Tier 4
Engine Cooling Liquid
Engine Fuel Diesel
Horsepower 74
Turbocharged Engine

Yes

Performance

Rated Operating Capacity (ISO) 2,570 lb
Operating Capacity (50% of Tip) 3,670 lb
Tipping Load 7,343 lb
Operating Weight 9,113 lb
Travel Speed 6.2 mph
Travel Speed (2 - Speed Option) 8.7 mph
Ground Pressure (Rubber) 5.7 psi

Capacities

Fuel Tank 43.9 gal

Hydraulic System

System Relief @ Quick Couplers 3,500 psi
Auxiliary Std Flow 23 gal/min
Auxiliary High Flow n/a

Dimension

Length 136.8 in
Length Without Attachment 108.4 in
Length With Standard Bucket 72.9 in
Width 72.9 in
Width (With Bucket)  74 in
Height 81.3 in
Height With Operator Cab 81.3 in
Height to Bucket Hinge Pin 124 in
Reach @ Maximum Height 36 in
Length of Track on Ground

57.7 in
Track Width

12.6 in
T650 Key Features

What Makes the T650 Different

The Bobcat T650 is equipped with features that support strong breakout performance, attachment versatility and efficient operation - from high-flow hydraulics and two-speed travel to quick attachment changes, standard joystick controls and simplified maintenance.

Strong Breakout Force

Expect strong lift and tilt breakout performance from the T650 to help operators dig, load and move material more efficiently. It's built for demanding daily work where breakout force directly supports stronger material handling performance.

High Flow Hydraulics

The high-flow option delivers more hydraulic output for expanded attachment versatility, including trenchers, stump grinders, drum mulchers and more.

Two-Speed Travel

Spend less time traveling across the jobsite or between jobs with this option. Move faster—and get the job done sooner.

Standard or Selectable Joystick Control

Choose between classic hand and foot controls or selectable joystick controls (SJC), depending on your preference and work needs.

Non-DPF Engine

Engines meet emissions requirements without a diesel particulate filter (DPF), eliminating the need for time-consuming regeneration.

Deluxe Display With Rearview Camera Integration

The standard Deluxe Display gives operators a clear, easy-to-use view of machine information, and rearview camera integration adds jobsite awareness when backing up and maneuvering on the jobsite.

Compare the Family

Bobcat Compact Track Loaders

Bobcat T450 compact track loader
T550
 Bobcat T595 compact track loader
T62
 Bobcat T64-2 compact track loader Bobcat T66-2 compact track loader Bobcat T7X all-electric compact track loader Bobcat T650 compact track loader Bobcat T770 compact track loader Bobcat T76-2 compact track loader Bobcat T86-2 compact track loader
T450 T550 T595 T62 T64-2 T66-2 T7X T650Viewing T770 T76-2 T86-2
Frame / RoleCompact classicMid-size classicCurrent classicNon-current mid-frameMid-frameMid-frameAll-electricLarger classicLargest classicLarge-frameHigh-output large-frame
Horsepower55 hp68 hp70 hp68 hp68 hp74 hp100 hp74 hp92 hp74 hp115 hp
Rated Operating Capacity1,490 lbs1,995 lbs2,100 lbs2,150 lbs2,300 lbs2,400 lbs3,056 lbs2,500 lbs3,475 lbs2,900 lbs3,925 lbs
Tipping Load4,257 lbs5,700 lbs6,000 lbs6,143 lbs6,571 lbs6,857 lbs8,743 lbs7,143 lbs9,929 lbs8,285 lbs11,214 lbs
Operating Weight6,424 lbs7,557 lbs7,906 lbs8,612 lbs8,440 lbs8,560 lbs12,590 lbs8,980 lbs10,515 lbs9,592 lbs12,104 lbs
Travel Speed7 / 11 mph7.1 / 10.4 mph7.1 / 10.4 mph7.2 mph6.4 / 9.3 mph5.5 / 9.3 mph5.7 / 8.7 mph6 / 8.7 mph6.6 / 10.7 mph6.8 / 9.2 mph5.5 / 10.7 mph
Standard Aux Flow16.7 gpm17.1 gpm17.1 gpm17.6 gpm17.6 gpm17.6 gpmNo hydraulics23 gpm23 gpm23.3 gpm23 gpm
High / Super Flow—26.7 gpm26.7 gpm26.9 gpm26.9 gpm26.9 gpm—30.5 gpm36.6 gpm30.3 gpm36.6 / 42 gpm
Height to Hinge Pin109.5 in114.5 in119 in114.5 in120 in120 in128.4 in124 in132 in128.3 in144 in
Overall Width55 in67 in66.6 in67 in67.8 in67.8 in78 in72.9 in78 in73.5 in78 in

Specs are model-level published values. Confirm final configuration, options and current availability with your Carleton Equipment location.

T650

T650 Features & Benefits

Performance
74 HP Midsize Power

The Bobcat T650 delivers 74 hp with a 2,500 lb rated operating capacity and 7,143 lb tipping load for demanding digging, grading, loading and material handling.

Strong Breakout Force

Strong lift and tilt breakout performance helps operators dig into piles, load trucks and move heavy material with confidence.

High-Flow Hydraulics

Standard auxiliary flow is 23 gpm, with optional high flow up to 30.5 gpm for higher-demand Bobcat attachments.

Two-Speed Travel Option

Two-speed travel gives the T650 an 8.7 mph high range, helping crews move faster between tasks on larger jobsites.

Comfort & Control
Selectable Control Choices

Operators can choose selectable joystick controls or classic hand and foot controls to match preference, experience and job demands.

Cab Comfort Options

Open cab and enclosed HVAC cab options let owners configure the T650 for seasonal work, long days and operator comfort.

Deluxe Display With Rearview Camera Integration

The standard Deluxe Display and rearview camera integration support clearer machine information and better awareness while backing and maneuvering.

Simple Package Choices

Work, Core and Comfort Plus packages make it easier to choose the right mix of speed, ride control, attachment controls and cab features.

Serviceability
Non-DPF Engine

The non-DPF emissions system avoids diesel particulate filter regeneration, helping operators stay productive during the workday.

Engine Shutdown Protection

Standard engine shutdown protection helps protect key systems when operating conditions move outside normal limits.

Lift-Arm Support

Standard lift-arm support helps make routine service and inspections more practical.

Bobcat Dealer Support

Carleton Equipment supports the T650 with Bobcat parts, service, attachments and local product knowledge across Michigan.

Versatility
Bob-Tach Attachment System

The standard Bob-Tach attachment system connects the T650 to a wide range of Bobcat loader attachments.

Power Bob-Tach Option

Optional Power Bob-Tach lets operators change many non-hydraulic attachments quickly from the cab.

Attachment-Ready Classic CTL

High-flow capability, track traction and familiar Bobcat operation make the T650 a strong match for construction, landscape, utility, snow and farm work.

Bobcat T650 Compact Track Loader

Why Buyers Choose the T650

74 hp and 2,500 lb rated operating capacity for a strong midsize classic CTL

7,143 lb tipping load and strong breakout performance for digging, loading and material handling

Optional high-flow hydraulics up to 30.5 gpm for higher-demand attachments

Optional two-speed travel reaches up to 8.7 mph for faster jobsite movement

Selectable joystick or classic hand and foot control choices fit different operator preferences

Non-DPF engine, Deluxe Display and rearview camera integration support daily uptime and visibility

Customers & Applications

Who Uses the T650 and What For

The T650 is a proven midsize classic compact track loader for customers who want more ROC, stronger hydraulics and balanced everyday performance in a straightforward package.

Contractors & Site Prep

  • Digging, grading, loading and site cleanup
  • Moving pallets, aggregate, soil and demolition debris
  • Running buckets, forks, grapples, breakers and trenchers
  • Working where track traction helps maintain production

Landscaping & Grounds

  • Preparing hardscape bases and spreading material
  • Using soil tools, brush tools, augers and snow attachments
  • Operating on softer or uneven terrain where tracks help flotation
  • Handling seasonal property maintenance and snow removal

Rental & Fleet Owners

  • Proven classic CTL platform with broad customer appeal
  • Optional high flow expands attachment rental opportunities
  • Work, Core and Comfort Plus packages simplify machine selection
  • Supported by Carleton Equipment parts, service and attachment expertise
Compact Track Loaders

Two Paths: Classic or Pro

Not sure which tier fits your application? Compare the full CTL lineup side by side.

Explore the Lineup

Full Specifications

General
ConditionRental
Machine TypeCompact Track Loader
Engine
Engine MakeBobcat
Alternator90A
Battery Size1000A
Engine-High Idle2,600 RPM
Engine-Low Idle1,150 RPM
Air Cleaner ElementsReplacable dry paper cartridge with seperate safety element
Horsepower74.0
EmissionsTier 4
Performance
ROC Solid Undercarriage2,570 lb
Rated Operating Capacity 200 lb. Counterweight2,600 lbs (200 lb counterweight) / 2,675 lbs (300 lb counterweight)
Loader Lift Height124 in
Bucket Hinge Pin Height124 in.
Reach @ Max Height36 in
Tipping Load7,343 lb
Travel Speed6.2-8.7 mph
Capacities
Fuel Tank43.9 gal.
Hydraulics
System Relief @ Quick Couplers3,450 psi
Auxiliary Std Flow23 GPM
Auxiliary High Flow30.5 gpm
Aux System Pressure3,500 psi
Dimensions & Weight
Ground Pressure5.7 psi
Height81.3 in.
Length108.4 im
Width72.9 in.
Operating Weight9113 lb
Turning Radius85 in
Length of track on ground58.5 in
Track Width12.6 in
Track Width - Optional17.7 in
Length with Standard Bucket136.8 in
Serviceability
Features
Joystick Control○ Optional
Air Conditioning○ Optional
Backup Alarm■ Standard
BICS System (Interlock)■ Standard
Cab Enclosure○ Optional
ROPS-Step— Not Applicable
Sound Option○ Optional
Cab Heater○ Optional
Operating Lights■ Standard
Turbocharged Engine■ Standard
Rear Window■ Standard
Top Window■ Standard
Lift-Arm Support■ Standard
Grab Handles— Not Applicable
Seat Belt■ Standard
Suspension Seat■ Standard
Two Speed Travel○ Optional
Deluxe Instrumentation○ Optional
Lockable Ignition— Not Applicable
Engine Shutdown■ Standard
Hydraulic Bucket Positioning○ Optional
High Flow Option○ Optional
Auxiliary Hydraulics■ Standard
3-Spool Valve— Not Applicable
Spark Arrestor Muffler■ Standard
Bob-Tach Attachment System■ Standard
Power Bob-Tach○ Optional
Horn■ Standard

Specifications subject to change without notice. Contact your local Carleton Equipment dealer to confirm details.
