E35 Long Arm - 69296

In Stock


Offers & Financing

Download Spec Sheet:

Download
General Info
Condition: New
Manufacturer: Bobcat
Model: E35
Machine Type: Compact Excavator
Year: 2024
Hours: 1.0
Stock Number: 69296
Coupler: X-Change
Excavator Class: 3.6 Ton
Engine
Emissions: Tier 4
Performance
Bucket Digging Force: 7,284 lbf.
Arm Digging Force: 4,690 lbf.
Max Digging Reach (Ground): 17 ft.
Max Digging Depth: 10.1 ft.
Operating Weight: 7659 lb
Hydraulics
Aux. Standard Flow: 16.9 GPM
Dimensions
Height: 96.2 IN.
Length: 190 IN.
Width: 69.7 IN.
Fuel Tank: 13.7 gal.

Description

New 2024 Bobcat E35 R2 Compact Excavator

Location:

461 East Fenn Road
Coldwater, Michigan 49036

Features:

  • Long Arm
  • X-Change
  • Keyless Ignition
  • Cloth Suspension Seat
  • Standard Blade
  • Clamp with Diverter Valve
Description

Part of the R-Series, the Bobcat® E35 compact (mini) excavator is a popular choice in the 3-ton size class. Zero Tail Swing (ZTS) provides unrestricted rotation, greater flexibility and reduced potential for damage to the machine and surrounding property. It’s available with an angle blade option, long arm option or clamp-ready extendable arm option. Upgrade to an optional 33 hp engine for even more productivity.

Specs
 Configuration Standard Long Arm Extendable Arm

Engine



Emissions Tier (EPA) Tier 4
Engine Fuel Diesel
Maximum Governed RPM 2,550 rpm
Horsepower 24.8 hp
Turbocharged Engine

N/A

Optional Horsepower

N/A

Performance

Operating Weight 7,699 lb 8,377 lb 8,597 lb
Weight Class 3.5 t 3.8 t 3.9 t
Travel Speed - High 2.9 mph 2.9 mph 2.9 mph
Travel Speed - Low 1.6 mph 1.6 mph 1.6 mph
Arm Digging Force 4,859 lbf 3,986 lbf 4,478 lbf
Bucket Digging Force 6,968 lbf 6,968 lbf 6,968 lbf
Rated Lift Capacity 3232 lb 3130 lb 3011 lb
Lift Radius 118 in 118 in 118 in
Boom Swing - Left 75° 75° 75°
Boom Swing - Right 55° 55° 55°
Maximum Dig Depth 10.2 ft 11.2 ft 12.9 ft
Max Dump Height 11 ft 11.6 ft 12.5 ft
Maximum Reach at Ground Level 17.2 ft 18.1 ft 19.7 ft

Capacities

 Fuel Tank 13.7 gal

Hydraulic System

Auxiliary Std Flow 16.9 gal/min
Auxiliary Pressure 2,987 psi

Dimension

 Length 189.9 in 190.3 in 190.5 in
Overall Length in Travel Position 189.9 in 190.3 in 190.5 in
Width 69 in 69 in 69 in
Height 96.2 in 96.2 in  96.2 in
Height with Operator Cab 96.2 in 96.2 in 96.2 in
Attachments

Features may include:

  • Advanced Hydraulics
  • Predictable Control
  • Dual Flange Roller System
  • Fingertip Boom Swing Control
  • Deluxe Instrumentation
  • Depth Check System
  • Multiple Arm Configurations
  • Extendable Arm
  • Integrated Rear Counterweight
  • Angle Blade
  • 2-Speed Travel
  • Auto Shift Travel
  • Blade Float
  • In-Track Swing Frame
  • Multiple Tail Swing Configurations
  • Protection Technology
  • Protected Components
  • Keyless Start
  • Easy Machine Tie Downs
  • Steel Tracks
  • Integrated Slew Brakes
  • X-Frame Undercarriage
  • Reversible Cutting Edge
