You never stop pushing, and neither does DEVELON. Our rugged dozers are intentionally designed for your needs: delivering superior pushing power, excellent visibility, easy operation, advanced technologies and simple maintenance.
More premium features come standard with DEVELON dozers, including best-in-class horsepower, best-in-class and weight (DD100 base unit), fully electronic hydraulic controls, a rearview camera, ECO mode, blade shake function, heating and air conditioning system, 8-inch Smart Touch display and DEVELON Fleet Management telematics. The DD130 dozer is compatible with an optional 3D machine guidance and 3D machine control system.
DD130
Make
Develon
Model
1204J
Number of Cylinders
4
Rated Power Gross
145.8 HP
Max Torque (Gross)
524 lbf. ft. @ 1400 rpm
Displacement
269 in³
Bore & Stroke
4.1 in. x 5.0 in.
Starter
24 V, 10.5 HP
Battery (QTY 2)
2-12 V, 100 AH
Alternator
24 V, 100 amp
Air Cleaner
Dual Element
DD130
Main Pump
1 GPM x 35 GPM
Relief Pressure (Normal)
3,844 psi
DD130
Upper Rollers (Each Track)
2
Lower Rollers (Each Track)
8
Number of Shoes (Links per Side)
41
DD130
Travel Speed (Low-High)
0 - 5.6 mph
DD130
Sound Level
106 dB(A)
Cabin Sound Level
76 dB(A)
DD130
Fuel Tank
50 gal.
Def Tank
5 gal.
Cooling System (Radiator Capacity)
11.8 gal.
Engine Oil
3.3 gal.
Final Drive (Each Side)
1.2 gal.
Hydraulic Tank
20 gal.
Blade Types:
Blade Type
XL Blade
LGP Blade
Operating Capacity (without ripper)
30,865 lb.
31,747 lb.
Ground Pressure
5.8 psi
4.4 psi
Blade Capacity
4.6 yd³
5.5 yd³
Blade Width
122.2"
143.9"
Blade Width (Max Angle)
113"
132.7"
Blade Height
43.9"
Blade Angle (Max)
± 25°
Blade Rotate (Max)
± 8°
Blade Tilt (Adjustable)
52 - 58°
Blade Digging Depth
15.9"
Blade Clearance
11"
Optional Ripper:
Blade Type
XL Blade
LGP Blade
Ripper Penetration (Max)
73.2"
Ripper Beam Width
68.5"
Ripper Cut Width
34.3"
Ripper Shank Distance
21.4"
To compete and succeed, you need equipment that maximizes your job site productivity and bottom line. The DD130 does both, offering more premium features as standard and best-in-class horsepower.
The DD130 comes with a standard rearview camera, 8-inch Smart Touch display, blade shake function, Smart Key, heating and air conditioning system and ECO mode for fuel efficiency without compromising grading performance. DEVELON Fleet Management, the same telematics system used on other DEVELON equipment, is also standard.
The DD130 comes with a standard oscillating track system for stable ground contact and improved operator comfort.
The DD130 offers excellent visibility to enhance operator confidence and productivity. A narrow front nose hood design provides better visibility to the work. The cooling system is located in the rear of the machine and the in-line precleaner is placed under the hood — creating an unobstructed view to the blade.
In addition to the standard rearview camera that improves visibility to the job site, the design of the front cab pillars is minimized to further reduce obstructions. And all-glass doors help provide maximum visibility. Four high-illumination LED lights are also standard to improve visibility in low-light working conditions.
The DD130 offers an optional blade assist function. This 2D grading system makes precision grading easier for novice operators. The operator programs the needed inputs, and the machine controls blade functions — finishing the job faster and with better accuracy. No GPS or lasers required.
For accurate grading— the operator can program the machine to control the blade functions.
Electrohydraulic controls are standard, making the machine easier to operate, and the ergonomically designed joystick helps reduce operator fatigue.
An automatic blade tilt and lift control maximize the DD130’s performance.
