Description
Fecon FMX28 Mulching Head
Excavator Class: 3.5-10 Ton
Add versatility to your business with Bull Hog mulching attachments for excavators.
The FMX Series offers 28″, 36″, and 50″ models with a split ring rotor design and knife tools for maximum performance. Designed for 3.5 – 10 ton excavators from 12 – 40 gpm. This lighter design also allows you to mount on backhoes and side arm booms while still offering Fecon’s durable, heavy-duty design.
Bull Hog Benefits
- Split ring rotor system with two tool options - Cubit Knife or Cubit Carbide
- Low maintenance design to keep you mulching!
- Variable displacement hydraulic motors optimize rotor speed & torque for maximum production in small or larger material
MODEL | FMX28 | FMX36 | FMX50 |
---|---|---|---|
Excavator Class (TONS) | 3.5 - 8 | 5 - 10 | 5 - 10 |
Working Width | 28" | 36" | 50" |
Overall Width | 40" | 44" | 58" |
Weight (lbs.) | 750 lbs | 850 lbs | 1,050 lbs |
Flow Range (GPM) | 12 - 40 GPM | 12 - 40 GPM | 12 - 40 GPM |
Flow Range (LPH) | 45 - 151 | 45 - 151 | 45 - 151 |
Number of Tools | 14 | 18 | 22 |
Rotor Diameter | 15" | 15" | 15" |
Rotor Speed (RPM) | 2,400 | 2,400 | 2,400 |
Rotor Bearing Size (MM) | ST65 | ST65 | ST65 |
Motor | 1 x 45V | 1 x 45V | 1 x 45V |
