Bobcat® Grapple, Industrial

Bobcat



Bobcat® Grapple, Industrial

Grab and hold onto the toughest materials with the industrial grapple attachment.

Built for maximum power and reliability, the industrial grapple delivers easy handling of hard-to-manage materials in the industrial or construction setting. The two-arm design of larger industrial grapples provides strong, even biting force. With hydraulic controls, it’s easy to operate and can securely handle bulky or uneven loads. Smaller grapples have a single grapple arm.

Choose from a bucket or fork bottom for maximum load capability. Built for day-in, day-out duty, the industrial grapple sinks in to the toughest jobs all day, every day.

Top Tasks

  • Handle demolition rubble, building materials, recycling, salvage, or scrap materials

Design and Quality

From reinforced tines to larger cylinders and better hose routing, some industrial grapples are built better than others. Compare them side-by-side and learn how Bobcat offers better design and superior quality.

Visibility Challenge

Good sight lines are critical to sorting debris, securing odd-shaped objects, clamping tree limbs and more. In this simple comparison, you'll discover how Bobcat industrial grapples offer better views that lead to greater efficiency.

  • Dual Cylinders (Large Grapples Only): With tough Bobcat®-built cylinders, dual cylinders provide the ability to secure uneven loads. Bobcat grapples provide the highest clamping forces in the industry. In the closing force challenge video, see why Bobcat industrial grapples offer the force to handle stubborn materials and work faster.
  • Removable Hose Guide: Provides hose routing when the grapple is attached. Watch the design and quality video to see all of the Bobcat strengths.Better Hose Routing and Protection: Reduces exposure to snags and other hazards. Learn more about this advantage in the design and quality video.Replaceable Cutting Edge on Bucket Grapples: Standard equipment for bucket protection.
  • Replaceable Tapered Fork on Fork Grapples: Allows for picking up larger materials and leaving valuable dirt behind. Provisions for adding additional forks to narrow the space between fork tines.
  • Reinforced Tines: Backed by more steel and greater reinforcement. Watch the design and quality video to see the difference.
  • Open Grapple Design: Provides superior visibility to the work area. Compare the design of other brands by watching the visibility challenge video.
  • Greaseable Pivot Points: Provide long life for pins and bushings. Discover the maintenance headaches of other brands in the design and quality video.
  • Inertia-Welded Cylinder Ends: As a Bobcat exclusive design, the inertia-welded cylinder ends deliver strong, smooth operation by improving hydraulic cushioning at the end of the stroke.
Grapple Sizes 36" 48" 62" 7 Tines 66" 68"



General

Operating Weight 365 lb 448 lb 884 lb 937 lb 922 lb
Length 32.2 in 32.2 in 41.1 in 41.1 in 41.1 in
Width 36 in 48 in 62 in 66.9 in 68 in
Height 29.5 in 29.5 in 30.2 in 30.3 in 30.2 in
Number of Fork Teeth (Factory) N/A N/A N/A 7 N/A
Number of Fork Teeth (Possible) N/A N/A N/A 13 N/A
Grapple Width 36 in 48 in 62 in 66.9 in 68 in
Number of Grapple Tines 1 1 2 2 2
Number of Forks N/A N/A N/A 7 N/A
Open Height 41.3 in 41.3 in 42.5 in 32 in 45.8 in
Open Length 38.1 in 38.1 in N/A N/A N/A
Closed Height 29.5 in 30.4 in 30.2 in 32.1 in 37 in
Closed Length 32.2 in 32.2 in 41.1 in 37.2 in 41.1 in



Compatible Carriers

Skid-Steer Loaders
Bobcat A770

Bobcat S70

Bobcat S450



Bobcat S550







Bobcat S570





Bobcat S590





Bobcat S595





Bobcat S630





Bobcat S650



Bobcat S740





Bobcat S770





Bobcat S850



Compact Track Loaders
Bobcat T450



Bobcat T550





Bobcat T590





Bobcat T595





Bobcat T630





Bobcat T650





Bobcat T740



Bobcat T770



Bobcat T870



Toolcat™ Work Machine
Bobcat 5600

Bobcat 5610

Telehandler
Bobcat V519
Mini Track Loaders
Bobcat MT55



Bobcat MT85
