Angle Broom - Rental

Rental Length: Daily - $200
Price:
Sale price$200.00
More specifications
General Info
Condition: Rental
Manufacturer: Bobcat
Model: Angle Broom
Engine
Performance
Hydraulics
Dimensions

Description

Angle Broom Rental

A hydraulic motor powers the Bobcat angle broom, enabling it to consistently rotate and clear away dirt, snow, or debris. The broom can tilt up to 25 degrees in either direction, making it easy for the operator to push materials to the side. Additionally, the broom's rotation can be reversed to effectively clean hard-to-reach areas.

  • Clear away dirt, dried mud, light snow and other debris
  • Effective on driveways, sidewalks, parking lots, loading docks, warehouses and more

Rent an Angle Broom in Michigan

Daily Weekly Monthly
$200
$550 Call for Pricing Plans
Bobcat Angle Broom
Model 52" Broom 64" Broom 68" Broom 84" Broom
Weight 355 lb. 385 lb. 860 lb. 944 lb.
Length 48.3 in. 48.3 in. 61.8 in. 61.8 in.
Width 54.5 in. 67.5 in. 79.6 in. 96.4 in.
Boom Angling Hydraulic Hydraulic Hydraulic Hydraulic
Broom Bristle Diameter 26 in. 26 in. 32 in. 32 in.
Sweep Width - Fully Angled 48 in. 60 in. 63 in. 77 in.
Sweep Width - Straight 51.5 in. 63.5 in. 68 in. 84 in.
Flow Range 9-18 GPM 9-18 GPM 8-24 GPM 15-28 GPM
Angle Broom Key Features

What Makes the Angle Broom Different

A hydraulically driven attachment for sweeping dirt, debris and light snow across four available widths.

Hydraulically Driven Sweeping

Efficiently sweep and clean with the hydraulically driven angle broom attachment.

Heavy-Duty Bristles

Heavy-duty broom bristles create a cleaner path and sweep more snow or debris in one pass.

Reverse Bristle Rotation

Available on 68- and 84-inch brooms for enhanced cleaning along curbs, corners and obstacles.

Approved Attachment Applications

Reversible configurations work with approved M-Series and R-Series compact track loaders, skid-steer loaders and Toolcat utility work machines equipped with the 7-pin attachment control kit.

Angle Broom Video

Bobcat Angle Broom Attachment

Bobcat Angle Broom Attachment video thumbnail
Angle Broom

Angle Broom Features & Benefits

Features & Benefits 11
Self-Centering Hydraulic Angling

Keeps the attachment centered and helps prevent offset, supporting accurate sidewalk cleanup while reducing disturbance outside the desired cleaning area.

Compact Design

The compact, highly maneuverable angle broom attachment supports maximum efficiency.

Easy Maintenance

The quick-change rotor makes bristle replacement simple; removing two bolts releases the entire rotor.

Angle Control

Electric-over-hydraulic control adjusts the broom angle up to 25 degrees.

Fingertip Controls

Precisely control larger brooms with electric-over-hydraulic angling to finish work quickly and efficiently.

Multi-Directional Sweeping

Reverse bristle direction on 68- and 84-inch brooms to remove debris from curbs, gutters, corners and obstacles.

Flush Sweeping

Sweep closely along a curb or wall for improved cleaning.

High-Torque Motor

Provides maximum power for efficient sweeping, even when engaging heavier debris.

Storage Stand

Larger brooms include storage stands that help prevent bristle distortion. On 68- and 84-inch models, a lever swings the legs up or down and positions them closer to the bristles for easier attachment.

Patented Spring Design

Supports optimum down pressure, extended bristle life and excellent cleaning performance.

Heavy-Duty Bristles

Replaceable polypropylene wafer bristles provide excellent service life and cleaning ability.

Bristle Options 5
Poly Bristles

Good rigidity, long life and effective debris removal under normal sweeping conditions.

Standard Poly Bristles

Balanced flick action and durability for normal to severe cleanup applications.

Heavy-Duty Poly Bristles

Contain more poly for rigid work action and aggressive sweeping across varied surfaces.

Steel Wire Bristles

Flexible spring-steel wire cuts through difficult material such as heavy millings and packed mud; use with poly wafers.

Poly and Wire Combination

Combines poly flicking action with wire's aggressive cleaning ability for demanding debris.

Why Buyers Choose It

Fast, Controlled Cleanup Across Four Widths

Hydraulically driven bristles sweep dirt, dried mud, debris and light snow

Effective on driveways, sidewalks, parking lots, loading docks and warehouses

Hydraulic angling directs material away from the cleaned path

Multiple bristle choices match everyday and aggressive cleanup

Top Tasks

What the Angle Broom Attachment Does

Clear Debris

  • Clear dirt and dried mud
  • Sweep light snow
  • Remove leaves and other debris

Maintain Surfaces

  • Driveways and sidewalks
  • Parking lots and loading docks
  • Warehouses and jobsites

How It Works

  • A hydraulic motor rotates the broom continuously to sweep dirt, snow and debris away from the attachment.
  • Angle the broom in either direction up to 25 degrees to move material to the side.
  • Reverse broom rotation to clean difficult-to-access areas.

Required Components

  • Hose extension kit for small articulated loaders
  • Attachment control kit
  • Components are purchased separately

Compatible Equipment

  • 8 compact track loaders
  • 2 compact wheel loaders
  • 2 mini track loaders
  • 9 skid-steer loaders
  • 3 small articulated loaders
  • 2 telehandlers
  • 2 Toolcat utility work machines

Talk to a person about the Angle Broom

Carleton Equipment is a family-owned Michigan dealer, here since 1938. Sales, rental, service and parts all come from the same team, and we’ll connect you with the location nearest you.

  • Chesterfield
  • Coldwater
  • Grand Rapids
  • Howell
  • Kalamazoo
  • Livonia
  • Saginaw

Angle Broom Specifications

GeneralAngle Broom - 52"Angle Broom - 64"Angle Broom - 68"Angle Broom - 84"
Length48.26 in48.26 in61.8 in61.8 in
Model Name (Public)Angle Broom - 52"Angle Broom - 64"Angle Broom - 68"Angle Broom - 84"
Operating Weight355 lbs385 lbs860 lbs944 lbs
Width54.5 in67.5 in79.6 in96.4 in
Height28.6 in28.2 in34.6 in34.6 in

Specifications apply to the angle broom attachment configurations. Confirm width, required components and compatibility with Carleton Equipment.
